45
9.4. 3PC Single-Zone Specications
Outdoor Unit Model No. 3PC036S4S
Nominal Tons 3
Ambient Temperature
Operating Range - °F
Cooling 5 - 122
Heating 5 - 86
Energy Star Yes
Sound Data (dBA) Cooling/Heating 61.5
Refrigerant (R-410A) Charge furnished 7 lbs. 5 oz.
Maximum line length with furnished charge - ft. 30
Additional charge required per ft. - oz. 0.32
Compressor No. and Type (1) Rotary
Refrigerant oil type VG74
Refrigerant oil charge - oz. 22.7
Connections - in. Liquid/Gas pipe (are) 3/8 / 5/8
Maximum refrigerant pipe length - ft. 213
Max. difference in level of indoor unit - ft. 98
Outdoor Fan(s) (No.) Diameter - in. (1) 22
Total air volume - cfm 2235
rpm 1150
Outdoor Coil Number of rows 3
Fins per inch 18
Fin type Hydrophilic aluminum
Tube outside diameter - in. 5/16
Tube type Ried copper tubing
Net face area - ft.
2
8.14
Application area - sq. ft. 515 - 750
Design Pressure PSIG 550 / 340
Shipping Data Net/Shipping weight (lbs.) 150 / 159
ELECTRICAL DATA
Electrical Characteristics - 60 Hz - 1 Phase 208/230V
1
Maximum Overcurrent Protection (amps) 35
2
Minimum circuit ampacity 28
Outdoor Fan Motor Rated load amps 0.5
Output - W 120
NOTE - Extremes of operating range are plus and minus 10% of line voltage.
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
