Page 3
XC14 SERIES
Typical Unit Parts Arrangement
LIQUID LINE FILTER
DRIER (SINGLE−FLOW)
FIELD CONNECTION
FOR LIQUID LINE SET
LIQUID LINE SERVICE
VALVE
SUCTION LINE
SERVICE VALVE
FIELD CONNECTION
FOR SUCTION LINE
MUFFLER
HIGH PRESSURE
SWITCH (S4)
COMPRESSOR
HARNESS
GROUND LUG
SINGLE POLE
CONTACTOR−1POLE (K1−1)
DUAL RUN CAPACITOR
(C12)
CONTROL PANEL
PLUMBING AND SWITCHES COMPONENTS
COMPRESSOR
DISCHARGE
LINE
CRANKCASE HEATER THERMO-
STAT (S40) (−041, −047, −048 AND
−060 UNITS ONLY)
THERMAL PROTECTION
SWITCH (S5)
SWITCH
COVER
THERMAL PROTECTION
SWITCH (S173) (ONLY ON
−036 AND −060)
Figure 1. Typical Parts Arrangements
