Lennox XC17-036 User Manual

XC17 - 2 to 5 Ton Air Conditioner / Page 10
SPECIFICATIONS
General
Data
Model No. XC17-024 XC17-030 XC17-036 XC17-042 XC17-048 XC17-060
Nominal Tonnage 2 2.5 3 3.5 4 5
Connections
(sweat)
Liquid line (o.d.) - in. 3/8 3/8 3/8 3/8 3/8 3/8
Suction line (o.d.) - in. 3/4 3/4 7/8 7/8 7/8 1-1/8
Refrigerant
1
R-410A charge furnished 7 lbs.14 oz. 8 lbs. 0 oz. 7 lbs. 12 oz. 7 lbs. 14 oz. 12 lbs. 12 oz. 12 lbs. 14 oz.
Outdoor
Coil
Net face
area - sq. ft.
Outer coil
23.25 27.21 27.21 27.21 27.21 27.21
Inner coil
- - - - - - - - - - - - 26.36 26.36
Tube diameter - in. 5/16 5/16 5/16 5/16 5/16 5/16
No. of rows
1 1 1 1 2 2
Fins per inch
26 26 26 26 22 22
Outdoor
Fan
Diameter - in. 26.2 26.2 26.2 26.2 26.2 26.2
No. of blades 5 5 5 5 5 5
Motor hp 1/4 1/4 1/4 1/4 1/4 1/4
Cfm 2650 3055 4025 4025 4230 4230
Rpm 400 450 600 600 675 675
Watts 37 53 122 122 185 185
Shipping Data - lbs. 1 pkg. 263 285 286 311 344 349
ELECTRICAL DATA
Line voltage data - 60hz - 1 ph 208/230V 208/230V 208/230V 208/230V 208/230V 208/230V
2
Maximum overcurrent protection (amps) 30 30 30 40 50 50
3
Minimum circuit ampacity 18.9 18.0 19.6 24.4 29.3 33.3
Compressor Rated load amps 13.5 12.8 14.1 17.9 21.8 25.0
Locked rotor amps 58.3 64.0 77.0 107.0 117.0 134.0
Power factor .97 .98 .98 .93 .96 .98
Outdoor Fan Motor Full load amps 2 2 2 2 2 2
OPTIONAL ACCESSORIES - MUST BE ORDERED EXTRA
icomfort Touch™ Thermostat 49W95
     
3
Remote Outdoor Temperature Sensor
(for dual fuel and Humiditrol
®
)
X2658
     
4
Discharge Temperature Sensor 88K38
     
ComfortSense
®
7000 Thermostat Y0349
     
Outdoor Temperature Sensor - for
ComfortSense 7000 Thermostat
X2658
     
Compressor Hard Start Kit 88M91
     
Compressor Low Ambient Cut-Off 45F08
     
Freezestat 3/8 in. tubing 93G35
     
5/8 in. tubing 50A93
     
Indoor Blower Off Delay Relay 58M81
     
Low Ambient Kit 68M04
     
Refrigerant
Line Sets
L15-41-20 L15-41-40
L15-41-30 L15-41-50
 
L15-65-30 L15-65-40
L15-65-50
  
Field Fabricate

NOTE - Extremes of operating range are plus 10% and minus 5% of line voltage.
1
Refrigerant charge sufcient for 15 ft. length of refrigerant lines.
2
HACR type breaker or fuse.
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
3
Remote Outdoor Sensor may be used with an icomfort™-enabled outdoor unit for a secondary (alternate) sensor reading. Sensor may also be used with a conventional
outdoor unit.
4
Optional for service diagnostics.
