Lennox XC17-036 - TXV USAGE; MOST POPULAR MATCHES

XC17 - 2 to 5 Ton Air Conditioner / Page 13
*tXV SUBSTITUTIONS
Indoor Coils/Air Handlers with factory installed expansion
valves that require eld replacement
Model No.
Indoor Coil or
Air Handler
Order No.
XC17-030 CBX32M-042 37L51
XC17-030 CBX32M-048 37L51
XC17-030 CX34-42 37L51
XC17-030 CX34-43 37L51
XC17-030 CX34-44/48 37L51
XC17-036 C33-44 39L72
XC17-036 CBX27UH-036 39L72
XC17-036 CBX32M-030 39L72
XC17-036 CBX32M-036 39L72
XC17-036 CBX32MV-024/030 39L72
XC17-036 CBX32MV-036 39L72
XC17-036 CBX40UHV-030 39L72
XC17-036 CBX40UHV-036 39L72
XC17-036 CX34-36 39L72
XC17-036 CX34-38 39L72
XC17-036 CX34-49 39L72
XC17-036 CX34-50/60 39L72
XC17-036 CX34-62 39L72
XC17-042 C33-44 39L72
XC17-042 C33-48 39L72
XC17-042 CBX27UH-048 39L72
XC17-042 CBX32M-036 39L72
XC17-042 CBX32M-048 39L72
XC17-042 CBX32MV-036 39L72
XC17-042 CBX40UHV-036 39L72
XC17-042 CX34-38 39L72
XC17-042 CX34-49 39L72
XC17-042 CX34-50/60 39L72
XC17-042 CX34-62 39L72
XC17-048 CBX32MV-036 91M02
XC17-048 CBX40UHV-036 91M02
XC17-048 CX34-44/48 91M02
XC17-060 CX34-44/48 91M02
* Factory installed expansion valve on the indoor coil or air handler shown
must be replaced with the expansion valve listed (ordered separately).
TXV USAGE
Model No. Order No.
XC17-024 37L51
XC17-030 37L51
XC17-036 39L72
XC17-042 39L72
XC17-048 91M02
XC17-060 91M02
CX34 upow coils and all Lennox air handlers (except CB26UH “R”) are
shipped with a factory installed TXV. In most cases, no change out of the valve
is needed.
If a change out is required it will be listed in the “TXV SUBSTITUTIONS” table.
The correct TXV must be ordered and eld installed. C33 coils and all horizon-
tal and downow coils are shipped without a TXV. The TXV must be ordered
and eld installed.
MOST POPULAR MATCHES
Outdoor Unit
Model No.
Indoor Unit
Model No
XC17-024
CX34-31
XC17-030 CX34-31
XC17-036 CX34-38
XC17-042 CX34-50/60C
XC17-048 CX34-50/60C
XC17-060 CX34-62D
