Lenovo 3000 C200 User Manual

6
User Guide
1.5.4 If you have audio devices, attach them using the
following instructions:
12
Microphone Use this connector to attach a microphone (purchased separately)
to your computer when you want to record sound or if you use
speech-recognition software.
Headphone Use this connector to attach headphones (purchased separately)
to your computer when you want to listen to music or other
sounds without disturbing anyone.
1.5.5 If you have powered speakers with an adapter:
(This picture is only a sketch print, it does not show the actual figure of the speaker)
a. Connect the cable that runs between the speakers if necessary. On some
speakers, this cable is permanently attached.
b. Connect the adapter cable to the speaker if necessary. On some speakers, this
cable is permanently attached.
c. Connect the speakers to the Headphone port on the computer.
d. Connect the adapter to the power source.

Lenovo 3000 C200 Specifications

General

Processor cache	1 MB
Processor family	Intel® Celeron® M
Processor frequency	1.6 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	533 MHz
Motherboard chipset	Intel® 945GM Express
HDD speed	5400 RPM
HDD interface	-
Optical drive type	DVD-RW
Card reader integrated	Yes
Total storage capacity	80 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, xD
Display diagonal	15 \
Display resolution	1024 x 768 pixels
Native aspect ratio	4:3
Internal memory	0.5 GB
Memory clock speed	667 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	2 GB
Memory layout (slots x size)	1 x 0.5 GB
Discrete graphics card model	Intel® GMA 950
Maximum graphics card memory	- GB
Type	PC
Power supply type	DC
Power requirements	AC, 100 - 240 V, 50 - 60 Hz
TV tuner integrated	No
Audio system	HD Audio
Networking features	Fast Ethernet
Operating system installed	Windows XP Home Edition
Certification	FCC Class-B FCC Rules Part 15 VCCI Class B CISPR22 Class B UL 60950 CSA C22.2 No. 950 NOM SASO IEC 60950 ACA MPR-II CE Mark CCC BSMI CER
Sustainability certificates	ENERGY STAR
Battery capacity	2400 mAh
Battery life (max)	2.5 h
Number of battery cells	6
AC adapter power	65 W
TV-out type	S-Video
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	4
CardBus PCMCIA slot type	Type II
Product color	Black
Pointing device	Touchpad

Weight and Dimensions

Depth	277.5 mm
Width	333.6 mm
Weight	2900 g
Height (rear)	33.8 mm
Height (front)	37 mm
