Lenovo H430 Hardware Replacement Guide

1
Hardware Replacement Guide
Overview
This guide is intended to be used by customers who are replacing Customer
Replaceable Units (CRUs) as well as trained service personnel who are replacing
Field Replaceable Units (FRUs). In this guide, CRUs and FRUs will be referred to as
parts.
Note: Trained service personnel should refer to the Hardware Maintenance
Manual (HMM) for parts ordering information.
This guide does not include procedures for all parts. It is expected that cables,
switches, and certain mechanical parts can be replaced by trained service
personnel without the need for step-by-step procedures.
Note: Use only parts provided by Lenovo™.
The description of the TV card in this manual applies only to machines which have
a TV card. It does not apply to machines which do not have a TV card.
This guide contains procedures for replacing the following parts:
• Memorymodules
• Harddiskdrive
• Opticaldrive
• GraphicCard
• TVTuner
• WLANCard
• Heatsink&Fan
• Keyboard
• Mouse
Safety information for replacing CRUs
Do not open your computer or attempt any repair before reading the
“Important safety information” in the Safety and Warranty Guide that was
included with your computer. If you no longer have this copy of the Safety
and Warranty Guide,youcanobtainoneonlinefromtheSupportWebsiteat
http://consumersupport.lenovo.com.

Lenovo H430 Specifications

General

Tcase	69.1 °C
Bus type	DMI
Stepping	Q0
Processor cache	2 MB
Processor cores	2
Processor model	G530
System bus rate	5 GT/s
Processor family	Intel® Celeron®
Processor socket	LGA 1155 (Socket H2)
Processor codename	Sandy Bridge
Processor frequency	2.4 GHz
Processor cache type	L3
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	24
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066 MHz
Memory bandwidth supported by processor (max)	16 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	5.1
Product type	PC
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Maximum internal memory	8 GB
Memory layout (slots x size)	- GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD±RW
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	Memory Stick (MS), MMC, MMC+, MS PRO, SD, SDHC
Speakers	No
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1000 MHz
Operating system installed	FreeDOS
USB 2.0 ports quantity	6
Firewire (IEEE 1394) ports	0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Tower
Product color	Black
Processor code	SR05H
Processor ARK ID	53414
Processor package size	37.5 x 37.5 mm
Supported instruction sets	SSE4.1, SSE4.2

Weight and Dimensions

Depth	430 mm
Width	175 mm
Height	368 mm
Weight	8000 g
