Lenovo IdeaPad 1 15IJL7 Ua User Manual

Left
1. Power connector
Connect to power with the included power cord and ac power
adapter.
2. Charging light Indicate whether the computer is connected to ac power.
• Solid white: connected to ac power; battery capacity 91%–100%
• Solid amber: connected to ac power; battery capacity 1%–90%
• Off: not connected to ac power
3. USB (3.2 Gen 1) Type-A connector Connect a USB-compatible device, such as a USB keyboard, a USB
mouse, a USB storage device, or a USB printer.
4. HDMI
™
1.4 connector
Connect to a compatible digital audio device or video monitor, such
as an HDTV.
5. USB-C
®
connector Connect external storage or data devices.
Note: An appropriate adapter may be needed for connecting external
devices. This connector cannot be used to connect external display
devices.
6. Combo audio jack Connect headphones or headsets with a 3.5 mm (0.14 inch), 4-pole
plug.
Note: This jack does not support standalone external microphones. If
you use headsets, choose one with a single plug.
Chapter 1. Meet your computer 3

Lenovo IdeaPad 1 15IJL7 Ua Specifications

General

Audio	2 x 1.5W speakers, Dolby Audio
Display	15.6" HD (1366x768) TN, 220 nits, anti-glare
RAM	4GB DDR4
Storage	128GB eMMC
Graphics	Intel UHD Graphics 600
Operating System	Windows 11 Home
Battery	42Wh
Weight	1.6 kg (3.5 lbs)
Camera	720p HD with privacy shutter
Dimensions	17.9 mm (0.70 inches)
WLAN + Bluetooth	Wi-Fi 5 11ac, 2x2 + Bluetooth 5.0
Ports	HDMI 1.4b
Processor	Intel Celeron N4020
