Lenovo IDEAPAD Y460 User Manual

Chapter 2. Learning the basics
31
Using Switchable Graphics (specific models
only) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Some IdeaPad models support Switchable Graphics. With this technology,
you have the flexibility to switch between a dedicated AMD
®
GPU*
(high-
performance GPU) and an integrated Intel GPU (power-saving GPU)
without restarting the Windows operating system.
*GPU is short for graphics processing unit.
To change the GPU, do the following:
1 Start your computer to the Windows operating system. If the computer
is in sleep or hibernation mode, press the power button to wake it up.
2 Activate the Switchable Graphics dialog box. To activate the dialog
box, you can:
• right-click on the desktop and select Configure Switchable Graphics from the
pop-up menu.
• slide and release the GPU switch on the front side of your computer.
Note: The dedicated AMD GPU provides you with superior graphics performance
while the energy-efficient integrated graphics provides longer operation with
the battery. You can switch to the high-performance GPU to gain the best
graphics performance. However, when the computer is using battery power
you are advised to switch to the power-saving GPU if you are not running
graphics-intensive applications.
Note: Do not try to change the GPU when the computer is in sleep or hibernation
mode.

Lenovo IDEAPAD Y460 Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-300 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.13 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	-
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD-RW
Card reader integrated	Yes
Total storage capacity	320 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, xD
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Type	PC
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Internal memory	2 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Discrete graphics card model	Intel HD
Maximum graphics card memory	- GB
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	667 MHz
Speaker power	3 W
Front camera resolution (numeric)	1.3 MP
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Home Basic
Sustainability certificates	ENERGY STAR
Battery life (max)	5 h
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
Product color	Black
Pointing device	Touchpad
Processor code	SLBNF
Processor ARK ID	47663
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1, SSE4.2

Weight and Dimensions

Depth	235 mm
Width	340 mm
Weight	2200 g
Height (rear)	33 mm
Height (front)	20 mm
