PC system bus adapter 2173 / 2177
L
10 PC system bus adapter EN 1.1
5.3.1.2 Detection of system settings for the LPT interface
Windows 9x/Me
1. Sele ct SettingsWControl panel.
2. Double-click the symbol System.
3. Select the register card Controller man ager.
4. Sele ct Ports (COM and LPT) and select the LPT port which is used by the system bus adapter
and click Properties.
5. Select the register card Resources to get a list of the settings for the I/O section and interrupt
(IRQ).
– The I/O address is the first number of the I/O section:
6. Accept the settings for Interrupt and I/O address in the system bus configuration tool.
Windows NT
1. Sele ct ProgramsWAdministration (general)WWindows NT diagnostics
2. Select the register card Resources
3. Click IRQ to get a list of all interrupts assigned.
– Use the IRQ indicated for the entry Parport in the system bus configuration tool. If the entry
Parport is not available, enter an interrupt between 1 and 15 in the system bus configuration
tool which is not indicated in this list.
4. Click I/O port t o get a list of all drivers.
5. Go t o Device and click the entr y Parport.
– The I/O range used for the LPT interface is indicated directly in front of the entry. The I/O
address is the first number of the I/O section:
Tip!
If a PC has several LPT interfaces, the entr y Parport is also available several times.
• Select the entry Parport for the LPT interface which is used by the system bus adapter.
• The entry with the highest I/O range is designed for the LPT interface with the lowest
connection number. (Sta ndard setti ng: L PT1 = I/O a ddress 378, L PT2 = I/O a ddress 278)
6. Accept the settings for Interrupt and I/O address in the system bus configuration tool.
Windows 2000/XP
1. Sele ct ProgramsWAccessoriesWSystem programsWSystem information
2. Sele ct Hardware resources and click the entry IRQ to get a list of all interrupts assigned.
– Use the IRQ indicated for the entry Printer connection (LPTx) in the system bus
configuration tool.
3. Sele ct Hardware resources and click the entry I/O to get a list of all drivers.
4. Sele ct t he Printer connection (LPTx) for the LPT interface to which the system bus adapter is
connected.
– The I/O range used for the LPT interface is indicated directly in front of the entry. The I/O
address is the first number of the I/O section:
5. Accept the settings for Interrupt and I/O address in the system bus configuration tool.
