PC system bus adapter 2173 / 2177
L
13PC system bus adapter EN 1.1
5.6 Checking and saving of the configuration
Click the button Check to check the current configuration.
• Only consistent configurations should be saved!
Press the button Exit to close the system bus configuration tool. The current configuration will be saved
automatically.
• When the configuration tool is closed the current configuration will be checked for consistency.
5.7 What’s coming next?
After the system bus adapter configuration has been completed, the Lenze tools can communicate via
the adapter.
• The Lenze tools only select the bus system. All system bus specific settings inc luding the
selection of the communication module are made by the system bus configuration tool.
Note!
Some of the older program versions of the Lenze tools still include possible settings for interrupt and
I/O address. When the driver update for PC system bus adapter 2177 is inst alle d these settings will
become void.
(^ 5)
