18
L
Part of the CE-typical drive system which is located on the
mounting plate
LOAD
LINE
Connect screen of the
motor cables at the motor
side as well, with a large
surface to PE.
Mains choke
LOAD
LINE
PE
RFI filter
L1 L2 L3
Paint-free bare metal
contact sufaces
Paint-free
surfaces for
screen contact
Paint-free surfaces
for screen contact
Paint-free
surfaces for
screen contact
Screened
control
cables
PE bar
PE connection
Mounting plate
conductive
connection
with PE
Controller
Screened
armature cable
Screened field cable
or laid together with
armature cable in the
motor system cable
NI K
ABL1 L2 L3PE
Paint-free surfaces
for screen contact
Second filter
(2-phase)
Connection mains fusing
N
L
480
