Technical data
EDK10200EV3 DE/EN/FR 5.0
L
PQ
PLC functionality
Field Number Description Data
Inputs
digital 8 Free inputs +24 VDC / 8 mA
per input
Reading and writing of the
inputs:
Shortest reading cycle: 1 ms
(depending on the site where
the process map is
generated)
analog 3 Free inputs
(10 bits + sign)
±10 V
Outputs
digital 4 Free outputs +24 VDC / max. 1 A
per output
Updating the outputs:
shortest upda te cycle is 1
ms (depending on the site
where the process map is
generated)
analog
1 Voltage output (10 bits
+ sign)
±10 V / max. 2 mA,
±0.5 %
1 Current output
(10 bits + sign)
±20 mA,
±0.5 %
