7
Installation
a
4 x M4
1.2 Nm
10 lb-in
4 x M6
2.8 Nm
24 lb-in
c
a1
b1
b2
s2s2
s1 s1
b
A
B
C
D
smd402
Type
a
[mm]
a1
[mm]
b
[mm]
b1
[mm]
b2
[mm]
c
[mm]
s1
[mm]
s2
[mm]
m
[kg]
ESMD371C2YXA
ESMD371C4TXA
93 84 146 128 17 100 15 50 0.6
ESMD751C2YXA
ESMD751C4TXA
93 84 146 128 17 120 15 50 0.9
ESMD112C4TXA 93 84 146 128 17 146 15 50 1.0
ESMD112C2YXA
ESMD152C4TXA, ESMD222C4TXA
114 105 146 128 17 133 15 50 1.4
ESMD152C2YXA, ESMD222C2YXA
ESMD302C2TXA
ESMD302C4TXA
114 105 146 128 17 171 15 50 2.0
ESMD402C2TXA
ESMD402C4TXA, ESMD552C4TXA
114 105 146 100 17 171 15 50 2.0
ESMD552C2TXA, ESMD752C2TXA
ESMD752C4TXA, ESMD113C4TXA
146 137 197 140 17 182 30 100 3.2
ESMD113C2TXA, ESMD153C2TXA
ESMD153C4TXA... ESMD223C4TXA
195 183 248 183 23 203 30 100 6.4
3 Installation
3.1 Mechanical installation
3.1.1 Dimensions and mounting
WARNING!
Drives must not be installed where subjected to adverse environmental conditions
such as: combustible, oily, or hazardous vapors or dust; excessive moisture; excessive
vibration or excessive temperatures. Contact Lenze for more information.
