Lenze 13466184 EDBSL03 v20 EN, DE, FR, IT, ES 13
Commissioning
Code Possible Settings
IMPORTANT
No. Name
Lenze
Selection
C00
Password entry 0 0 999 Visible only when password is active
(see C94)
C01
Setpoint and control
source
0 Setpoint source: Control conguration:
0 Analog input (terminal 8; see C34) Control = terminals
Programming = keypad
Monitoring = LECOM 1 Code c40
2 Analog input (terminal 8; see C34) Control = terminals
Programming = LECOM / keypad
Monitoring = LECOM
3 LECOM Control = LECOM
Programming = LECOM / keypad
Monitoring = LECOM
4 Analog input (terminal 8; see C34) Control = terminals
Programming = remote keypad
Monitoring = remote keypad5 Code c40
6 Analog input (terminal 8; see C34) Control = remote keypad
Programming = remote keypad
Monitoring = remote keypad7 Code c40
8 Analog input (terminal 8; see C34) Control = terminals
Programming = Modbus / keypad
Monitoring = Modbus9 Code c40
10 Analog input (terminal 8; see C34) Control = Modbus
Programming = Modbus / keypad
Monitoring = Modbus11 Code c40
Note
• When C01 = 1, 5, 7, 9, or 11, use c40 for speed setpoint
• When C01 = LECOM (3), write speed command to C46
C02
Load Lenze setting 0 No action/loading complete
• C02 = 1...4 only possible with
OFF or 1nh
• C02 = 2 : C11, C15 = 60 Hz
1 Load 50 Hz Lenze settings
2 Load 60 Hz Lenze settings
3 Load OEM settings (if present)
4 Translate
WARNING!
C02 = 1...3 overwrites all settings! TRIP circuitry may be disabled! Check codes
CE1...CE3.
NOTE
If an EPM that contains data from a previous software version is installed, C02 =
4 converts the data to the current version.
4.3 Parameter menu
