5 Electrical installation
Danger!
Hazardous electrical voltage
The electrical installation has to be carried out by skilled personnel in
compliance with electrotechnical regulations and standards.
5.1 Motor connection
To correctly connect the motor, please observe:
¯ the notes in the terminal box of the motor
¯ the notes in the Operating Instructions of the motor
¯ the technical data on the motor nameplate.
5.2 Motor options
To correctly connect the motor options, e. g. brakes or feedback systems, please observe:
¯ the notes in the corresponding terminal box
¯ the notes in the corresponding operating instructions
¯ the technical data on the corresponding motor nameplate.
