EDK82ZAFPC−001 DE/EN/FR 7.0
3
au_00ild−Legende
4
ON
AABB
CN
VP
7
40 39 28 20 59
7
+
0
2
3
1
E82ZAFPC001
E82ZAFP004/AFX009
0Abb. 0Tab. 0
Pos. Beschreibung Ausführliche
Information
DIP−Schalter zur Aktivierung des Busabschluss−Widerstandes
32
Status der PROFIBUS−Kommunikation (gelbe LED)
34
Verbindungsstatus zum Grundgerät (grüne LED)
Klemmenleiste X3, Anschluss für
l PROFIBUS
l Reglersperre (CINH)
l externe Spannungsversorgung
25
Typenschild 12
