Levoit Vital 100 User Manual

7
USING YOUR AIR
PURIFIER
1. Plug in and tap to turn the air purifier
on/o. The fan will start on level I.
2. Optionally, tap to cycle fan speeds
between I, II, and III.
General Operation
Note:
• The indicators are not buttons and
cannot be used to change the
fan speed.
• The fan speed indicators will light up
when active.
• Fan speed III is the loudest, but cleans
air the quickest.
• For best results, or to address a
specific air quality issue such as
smoke, run the air purifier at maximum
speed (level III) for 15–20 minutes
before using a lower speed.
• To eectively clean air, keep windows
and doors closed while the air purifier
is on.
Memory Function
When the air purifier is plugged in, it will
remember its previous fan speed setting.
Note: The air purifier will not remember
timers.
GETTING STARTED (CONT.)
3. Replace the back cover by lining up the
cover’s feet with the matching slots on
the bottom of the housing. [Figure 1.3]
4. Push the cover closed.
5. Place the air purifier on a hard,
flat surface. Leave 15 in / 38 cm of
clearance to allow air to pass through
the air inlets on the sides. [Figure 1.4]
Figure 1.3
Figure 1.4
15 in /
38 cm
15 in /
38 cm

Levoit Vital 100 Specifications

General

Timer	Yes
Efficiency	99.97 %
Noise level	50 dB
Certification	CARB, FCC, ETL
Air purify rate	221 m³/h
Number of speeds	3
Noise level (low speed)	23 dB
Operating temperature (T-T)	-10 - 40 °C
Suitable for room area up to	90.6 m²
Operating relative humidity (H-H)	0 - 85 %
Particle filtration	0.3 µm
Filtering capability	Cigarette smoke, Fine dust, Pollen
Control type	Touch
Display type	LED
Product color	White
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (max)	55 W

Weight and Dimensions

Depth	162 mm
Width	324 mm
Height	410 mm
Weight	4200 g
