Lexmark MX310dn Technical Reference

PostScript paper tray support
When the printer receives one of the operators listed in “Tray selected with tray operators” on page 11, it performs the
actions listed in this section. This paper tray selection process ends when a suitable paper source is chosen and paper is fed
from that source.
• The printer checks the value of manualfeed in statusdict and the ManualFeed page device parameter. If either one is true,
then the printer sends a message to load the requested size in the manual feeder or multipurpose feeder.
• The PageSize Policy is set to 0 by means of setpagedevice.
• The printer checks the paper size loaded in the current active source to determine if it matches the requested size. If the
sizes match, then the paper is fed from the active source.
Note: The current active tray is the last source that was selected from the control panel or by the printer language.
• If the requested size and the size loaded in the active source do not match, then the sources are searched in the order
defined by the Priority array in the InputAttributes dictionary in the pagedevice dictionary.
• If the requested media size is not found by the previous search, then the following search order is used:
– Tray 1
– Tray 2
– Tray 3
– Multipurpose feeder
– Tray 4
• If the requested size cannot be located in any automatic source, then a configurationerror is issued and the job is flushed.
For printers that support automatic two‑sided printing (duplexing):
• All papers, except custom‑size paper and envelopes, are supported for duplexing in the multipurpose feeder.
• If the paper source is changed before the back side of a two‑sided page prints, then a blank back page prints, the paper
source changes, and the information for the back side of the page is printed on the front side of a page sent from the new
paper source.
When these operators are used, it is equivalent to executing the following PostScript emulation sequence:
<< /PageSize [x y]/ImagingBBox null /Policies << /PageSize 0>> >>
setpagedevice
where x and y are the PageSize in points.
= Supported
X = Not supported
Printer model
Operator Tray selected
(corresponding image size
is set)
MS310, MS312, MS315,
MS410, MS415, MS510,
MS610
MX310, MX410,
MX510, MX511
MX610, MX611
11x17tray Tray with 11 x 17 in.‑size
paper
XXX
a3tray Tray with A3‑size paper XXX
a4tray Tray with A4-size paper
a5tray Tray with A5-size paper
a6tray Tray with A6-size paper
b4tray Tray with B4‑size paper XXX
b5tray Tray with B5-size paper
customtray Tray with custom-size paper XXX
executivetray Tray with executive-size
paper
PostScript (PS) emulation 11

Lexmark MX310dn Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Duplex print speed (black, normal quality, A4/US Letter)	14 ppm
Finishing option	No
All-in-one functions	Copy, Fax, Print, Scan
Supported media weight(s)	60 - 90 g/m²
Color all-in-one functions	Scan
Package dimensions (W x D x H)	19.09 x 21.65 x 22.48 \
Supported media weight (imperial)	24 lbs
Country of origin	China
Maximum duty cycle	50000 pages per month
Recommended duty cycle	250 - 6000 pages per month
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PostScript 3, PPDS
Copier resize	25 - 400 %
Copy speed (black, normal quality, A4)	33 cpm
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 356 mm
Duplex scan speed (black)	43 ppm
Duplex scan speed (color)	20 ppm
Optical scanning resolution	600 x 1200 DPI
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax transmission speed	3 sec/page
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Total number of input trays	2
Maximum number of input trays	3
Auto document feeder (ADF) input capacity	50 sheets
Envelopes sizes	7 3/4, 9, 10, DL
Maximum print size	-
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Display diagonal	2.4 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Supported network protocols (IPv4)	TCP/IP, AppleTalk, TCP, UDP
Supported network protocols (IPv6)	TCP/IP
Internal memory	256 MB
Processor frequency	800 MHz
Sound pressure level (copying)	54 dB
Sound pressure level (printing)	53 dB
Sound pressure level (scanning)	55 dB
Sound pressure level (duplex printing)	52 dB
Power consumption (average operating)	- W
Package depth	550 mm
Package width	485 mm
Package height	571 mm
Package weight	22500 g
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Sustainability certificates	ENERGY STAR
Certification	Blue Angel (RAL-UZ-122), CAN/CSA-C22.2 60950-1, CSA E60825-1, ICES-003 B, BSMI B, CNS 13438, VCCI B, US FDA, FCC B, UL 60950-1, IEC 320-1, EN/IEC 60320-1, CE B, CB IEC 60950-1, EN 62311, EN 60950-1, EN/IEC 61000-3, EN 55022 B, EN 55024, EN/IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, SMA C-tick B, CCC B, CISPIR 22 B, EK Mark, N Mark, ECMA-370, TED

Weight and Dimensions

Depth	472 mm
Width	399 mm
Height	468 mm
Weight	20000 g
