1. Application range
This specification is applied all of the LCD TV with LA75E
chassis.
2. Requirement for Test
Each part is tested as below without special appointment.
(1) Temperature : 20 ± 5°C
(2) Relative Humidity : 65 ± 10%
(3) Power voltage
: Standard input voltage(100-240V@50/60Hz)
*Standard Voltage of each products is marked by models.
(4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
(5) The receiver must be operated for about 30 minutes prior
to the adjustment.
3. Test method
(1) Performance : LGE TV test method followed
(2) Demanded other specification
Safety : UL, CSA, IEA Specification
EMC : FCC, ICES, IEC Specification
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
4. General Specification(TV)
No Item Specification Remark
1 Receivable System ATSC/64 & 256 QAM/ NTSC-M
2 Available Channel VHF : 02 ~ 13
UHF : 14 ~ 69
DTV : 02 ~ 69
CATV : 01 ~ 135
CADTV : 01 ~ 135
3 Input Voltage 100-240V~, 50/60Hz
4 Market NORTH AMERICA
5 Screen size 19 inch Wide
6 Aspect Ratio 16 : 9
7 Tuning System FS
8 LCD Module LM190WX1(1440*900) Wide, LPL
M190A1-L02(1440*900) Wide, CHI MEI
9 Operating Environment Temp : 0 ~ 40 deg
Humidity : 10~90 %RH
10 Storage Environment Temp : -20 ~ 50 deg
Humidity : 10~90 %RH
