LG 24MT47D User Manual

10
ENG
ENGLISH
Antenna connection
Connect the TV to a wall antenna socket with an RF cable (75 Ω)
(Not Provided).
NOTE
• Use a signal splitter to use more than 2 TVs.
• If the image quality is poor, install a signal amplifier properly to
improve the image quality.
• If the image quality is poor with an antenna connected, try to
realign the antenna in the correct direction.
• An antenna cable and converter are not supplied.
• Supported DTV Audio: MPEG, Dolby Digital, Dolby Digital Plus,
HE-AAC
Antenna Booster
(Depending on model)
• This feature improves the sensitivity to weak RF Signal in
poor reception areas. LG’s built-in booster is auto-activated at
weak signal level. It strengthens signal level and minimizes
picture colour noise.
• This feature is auto-controlled by processor and no user
intervention required.
Other connections
Connect your TV to external devices. For the best picture and audio
quality, connect the external device and the TV with the HDMI cable.
Some separate cable is not provided.
• USB port supports 0.5 A electric current. If you need more electric
current in case of HDD, use the separate power adaptor.
Connecting to a PC
Your TV supports the Plug & Play* feature and has the built-in
speakers with Virtual Surround that reproduces sound clearly with
a rich bass.
* Plug & Play: The function when a PC recognizes a connected device
that users connect to a PC and turn on, without device configuration
or user intervention.
NOTE
• If you want to use HDMI-PC mode, you must set the Input Label
to PC mode.
• The OSD (On Screen Display) is displayed on the screen as shown
below.
- When turning the product on in HDMI input.
- When switching to HDMI input.
Is the input connected to your PC?
Do not show message again
Yes No
• If you select "Yes" the size and image quality are optimised for
your PC.
• If you select "No" the size and image quality are optimised for the
AV device (DVD player, set-top box).
• If you select "Do not show message again" this message does
not appear until the TV is reset. You can change the set value in
SETTINGS INPUT Input Label.
• The values set for HDMI1/HDMI2 are saved independently. (Only
MT57*)

LG 24MT47D Specifications

General

3D	No
Aspect ratio	16:9
Response time	8.5 ms
Display diagonal	24 \
Display resolution	1366 x 768 pixels
Supported video modes	720p
Contrast ratio (dynamic)	5000000:1
Display number of colors	-
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1366 x 768
TV tuner integrated	Yes
Digital signal format system	DVB-C, DVB-T
USB hub version	2.0
RMS rated power	10 W
Number of speakers	2
Product color	Black
LED indicators	Power
Tilt angle range	-5 - 20 °
Panel mounting interface	75 x 75 mm
Power consumption (standby)	- W
Package depth	402 mm
Package width	700 mm
Package height	126 mm
Package weight	4800 g
Cables included	AC

Weight and Dimensions

Depth (with stand)	158.7 mm
Height (with stand)	393.8 mm
Weight (with stand)	3600 g
Depth (without stand)	53.1 mm
Width (without stand)	556 mm
Height (without stand)	345.2 mm
Weight (without stand)	3400 g
