EXTERNAL CONTROL DEVICE SETUP
Communication Parameters
• Baud rate : 9600 bps (UART)
• Data length : 8 bits
• Parity : None
• Stop bit : 1 bit
• Communication code : ASCII code
• Use a crossed (reverse) cable.
Command reference list
(Depending on model)
COMMAND1 COMMAND2
DATA
(Hexadecimal)
01. Power off k a 00
02. Aspect Ratio k c (See p.53)
03. Screen Mute k d (See p.53)
04. Volume Mute k e 00 to 01
05. Volume Control k f 00 to 64
06. Contrast k g 00 to 64
07. Brightness k h 00 to 64
08. Color/Colour k i 00 to 64
09. Tint k j 00 to 64
10. Sharpness k k 00 to 32
11. OSD Select k l 00 to 01
12. Remote Control Lock Mode k m 00 to 01
13. Balance k t 00 to 64
14. Color (Colour) Temperature x u 00 to 64
15. ISM Method (Only Plasma TV) j p (See p.54)
16. Energy Saving j q 00 to 05
17. Tune Command m a (See p.55)
18. Channel (Programme) Add/Del(Skip) m b 00 to 01
19. Key m c Key Codes
20. Control Back Light, Control Panel Light m g 00 to 64
21. Input select (Main) x b (See p.57)
22. 3D (Only 3D models) x t (See p.57)
23. Extended 3D (Only 3D models) x v (See p.58)
24. Auto Configure j u (See p.58)
* Note: During USB operations such as DivX or EMF, all commands except Power(ka) and Key(mc) are not
executed and treated as NG.
