EXPLODED VIEW PARTS LIST
112 6335V32018B CPT ASSEMBLY,W76QEP257X V2NLGD N(+0.40G) 0G
120 6400VA0025C SPEAKER,FULLRANGE C163P03K1450 8OHM 15/20W 84DB
150 6140VC2006H COIL,DEGAUSSING AL 65TURN 14.5OHM 0.80PIE 3800MM 32 2007J+D07D
170 170-797X CPT EARTH,32 144T 2LUG 1P*2 .
174 6410VUH004A POWER CORD,UL/CSA3000MM 3P 3000MM HUG BLACK 500MH 7A
300 3091V00528N CABINET ASSEMBLY,DU-32FZ40 STEREO AC02SC HDMI
310 5020V00794A BUTTON,CONTROL 32FZ40 ABS, HF-380 6KEY NON
330 5020V00553L BUTTON,POWER RN-17LZ11E ABS, HF-380 1KEY .
400 3809V00368N BACK COVER ASSEMBLY,DU-32FZ40 2PHONE AC-02SC
501 4810V00708H BRACKET,MAIN DU-32FZ40 AC02SC HIPS 40AF BK
503 4811V00186B BRACKET ASSEMBLY,REAR AV DU-32FZ40 AC02SC HDMI JACK
510 6871VSMQ28H PCB ASSEMBLY,SUB CRTMIN AC02SC DU-32FZ40 CPT BOARD
520 6871VMM780A PCB ASSEMBLY,MAIN AC-02SC DU-32FZ40
530 6871VDM920A PCB ASSEMBLY,DEFLECTION MAIN2 AC-02SC DU-32FZ40 M/I
550 6871VSMT89B PCB ASSEMBLY,SUB DIGITAL AC02SC DU-32FZ40 M/I
560 6871VSM696A PCB ASSEMBLY,SUB L/F AC02SC DU-32FZ40
570 6871VSM697A PCB ASSEMBLY,SUB PSW AC02SC DU-32FZ40
580 6871VSMW98A PCB ASSEMBLY,SUB CTL AC02SA CTL+INDEX DN-32FZ40H
600 6871VSMV60B PCB ASSEMBLY,SUB A/V AC02SA SIDE A/V DN-32FZ33H
700 0IGL120104K IC,DRAWING HSF-8007 LG INNOTEK DIP 3PIN HYBRID BULK CDS SENSOR
943 1PTF0403116 SCREW TAP TITE(P),TRUSS HEAD
