DVD
1
1
2
When connecting with a component cable
Connect the video outputs (Y, PB
, PR) of the DVD to the
CCOOMMPPOONNEENNTT IINN VVIIDDEEOO
jacks on the set.
Connect the audio outputs of the DVD to the
CCOOMMPPOO--
NNEENNTT IINN AAUUDDIIOO
jacks on the set.
Turn on the DVD player, insert a DVD.
1
2
3
Select
CCoommppoonneenntt
input source with using the
IINNPPUUTT
button on the remote control.
4
Refer to the DVD player's manual for operating instruc-
tions.
5
NOTE
GG
CCoommppoonneenntt IInnppuutt ppoorrttss
To get better picture quality,
connect a DVD player to the
component input ports as shown
below.
Y PB
PR
Component ports on the TV
Y
Y
Y
Y
Pb
B-Y
Cb
P
B
Pr
R-Y
Cr
P
R
Video output ports
on DVD player
When connecting with a Euro Scart
Connect the Euro scart socket of the DVD to the
AAVV11
Euro scart socket on the set.
Turn on the DVD player, insert a DVD.
Select AV 1 input source with using the
IINNPPUUTT
button on
the remote control.
- If connected to
AAVV22
Euro scart socket, select
AV 2 input
source.
1
2
3
NOTE
