LG 32LC51 Service Manual

- 28 -
* C100 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C0G -55TO+125C 160
C100 0CH5101K416 C2012C0G1H101JT 100pF 5% 50V C0G -55TO+125C 2
C100 0CH5101K416 C2012C0G1H101JT 100pF 5% 50V C0G -55TO+125C 2
C101 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C0G -55TO+125C 160
C101 0CE476VF6DC VGV476M016S0ANE010 47uF 20% 16V 70MA -40TO+85
C101 0CH5101K416 C2012C0G1H101JT 100pF 5% 50V C0G -55TO+125C 2
C102 0CE227SF6DC MVG6.3TP16VC220M 220uF 20% 16V 130MA -40TO+85
C102 0CE476VF6DC VGV476M016S0ANE010 47uF 20% 16V 70MA -40TO+85
C103 0CE106SF6DC VMV106M016S0ANB010 10uF 20% 16V - -40TO+85C G
C103 0CE476VF6DC VGV476M016S0ANE010 47uF 20% 16V 70MA -40TO+85
C104 0CE106SF6DC VMV106M016S0ANB010 10uF 20% 16V - -40TO+85C G
C104 0CH6330K416 C2012C0G1H330JT 33p 5% 50V C0G -55TO+125C 201
C105 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C0G -55TO+125C 160
C106 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C0G -55TO+125C 160
C110 0CK682CK51A C1608Y5P1H682KT 6.8nF 10% 50V Y5P -30TO+85C 1
C111 0CK682CK51A C1608Y5P1H682KT 6.8nF 10% 50V Y5P -30TO+85C 1
C112 0CK682CK51A C1608Y5P1H682KT 6.8nF 10% 50V Y5P -30TO+85C 1
C113 0CK682CK51A C1608Y5P1H682KT 6.8nF 10% 50V Y5P -30TO+85C 1
C114 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C0G -55TO+125C 160
C115 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C0G -55TO+125C 160
C116 0CE227SF6DC MVG6.3TP16VC220M 220uF 20% 16V 130MA -40TO+85
C117 0CE106SF6DC VMV106M016S0ANB010 10uF 20% 16V - -40TO+85C G
C118 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C0G -55TO+125C 160
C119 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C0G -55TO+125C 160
C120 0CE106SF6DC VMV106M016S0ANB010 10uF 20% 16V - -40TO+85C G
C200 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C0G -55TO+125C 160
C201 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C0G -55TO+125C 160
C204 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C205 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C206 0CE106SF6DC VMV106M016S0ANB010 10uF 20% 16V - -40TO+85C G
C206 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16V 16MA -40TO+105C
C213 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C0G -55TO+125C 160
C214 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C0G -55TO+125C 160
C215 0CK105CF94A 0603F105Z160CT 1uF -20TO+80% 16V Y5V -30TO+85
C216 0CK105CF94A 0603F105Z160CT 1uF -20TO+80% 16V Y5V -30TO+85
C217 0CK105CF94A 0603F105Z160CT 1uF -20TO+80% 16V Y5V -30TO+85
C218 0CK105CF94A 0603F105Z160CT 1uF -20TO+80% 16V Y5V -30TO+85
C219 0CK105CF94A 0603F105Z160CT 1uF -20TO+80% 16V Y5V -30TO+85
C220 0CK105CF94A 0603F105Z160CT 1uF -20TO+80% 16V Y5V -30TO+85
C221 0CK104CF56A 0603B104K160CT 100nF 10% 16V X7R -55TO+125C 1
C225 EAE32755801 CL31A106K5HNNNE 10uF 10% 16V X5R -55TO+85C 32
C226 EAE32755801 CL31A106K5HNNNE 10uF 10% 16V X5R -55TO+85C 32
C227 EAE32755801 CL31A106K5HNNNE 10uF 10% 16V X5R -55TO+85C 32
C302 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C303 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C307 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C308 0CC180CK41A C1608C0G1H180JT 18pF 5% 50V C0G -55TO+125C 16
C309 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C310 0CC180CK41A C1608C0G1H180JT 18pF 5% 50V C0G -55TO+125C 16
C311 0CE106SH6DC VMV106M025S0ANB010 10uF 20% 25V 20MA -40TO+85
C312 0CK103CK51A 0603B103K500CT 10nF 10% 50V Y5P -30TO+85C 160
C316 0CE106SH6DC VMV106M025S0ANB010 10uF 20% 25V 20MA -40TO+85
C316 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16V 16MA -40TO+105C
C317 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C318 0CE106SH6DC VMV106M025S0ANB010 10uF 20% 25V 20MA -40TO+85
C319 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C320 0CC220CK41A C1608C0G1H220JT 22pF 5% 50V C0G -55TO+125C 16
C321 0CC220CK41A C1608C0G1H220JT 22pF 5% 50V C0G -55TO+125C 16
C322 0CC220CK41A C1608C0G1H220JT 22pF 5% 50V C0G -55TO+125C 16
C400 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C401 0CC390CK41A C1608C0G1H390JT 39pF 5% 50V C0G -55TO+125C 16
C402 0CC390CK41A C1608C0G1H390JT 39pF 5% 50V C0G -55TO+125C 16
C403 0CE107SF6DC VMV107M016S0ANE010 100uF 20% 16V 91A -40TO+85
C404 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C405 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C406 0CK273CK56A 0603B273K500CT 27nF 10% 50V X7R -55TO+125C 16
C408 0CE227SF6DC MVG6.3TP16VC220M 220uF 20% 16V 130MA -40TO+85
C409 0CK273CK56A 0603B273K500CT 27nF 10% 50V X7R -55TO+125C 16
C410 0CC220CK41A C1608C0G1H220JT 22pF 5% 50V C0G -55TO+125C 16
C411 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C412 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C500 0CK225DD66A LMK212JB225MG-T 2.2uF 20% 10V X7R -55TO+125C
C501 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C502 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C503 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C504 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C505 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C506 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C507 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C508 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C509 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C510 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C511 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C512 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C513 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C514 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C515 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C516 0CE106SF6DC VMV106M016S0ANB010 10uF 20% 16V - -40TO+85C G
C516 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16V 16MA -40TO+105C
C517 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
C518 0CK103CK56A 0603B103K500CT 10nF 10% 50V X7R -55TO+125C 16
C519 0CK474CH94A 0603F474Z250CT 470nF -20TO+80% 25V Y5V -30TO+
C520 0CK474CH94A 0603F474Z250CT 470nF -20TO+80% 25V Y5V -30TO+
C521 0CK474CH94A 0603F474Z250CT 470nF -20TO+80% 25V Y5V -30TO+
C522 0CK474CH94A 0603F474Z250CT 470nF -20TO+80% 25V Y5V -30TO+
C525 0CK474CH94A 0603F474Z250CT 470nF -20TO+80% 25V Y5V -30TO+
C526 0CK474CH94A 0603F474Z250CT 470nF -20TO+80% 25V Y5V -30TO+
C527 0CE335WK6D8 MVK4.0TP50VC3.3M 3.3uF 20% 50V 14MA -40TO+105
C528 0CK104CK56A 0603B104K500CT 100nF 10% 50V X7R -55TO+125C 1
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
REPLACEMENT PARTS LIST
DATE: 2007. 02. 07.
CAPACITORs
www.freeservicemanuals.info
1/12/2013
Worldwide electronic heritage manuals

LG 32LC51 Specifications

General

Audio system	7w+7w
Number of speakers	2
I/O ports	PAL I/II, PAL/SECAM BG/DK/NTSC
Display diagonal	32 \
Display brightness	500 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Contrast ratio (typical)	5000:1
SCART ports quantity	1
Product color	Black
Power consumption (standby)	1 W
Power consumption (typical)	150 W

Weight and Dimensions

Depth (with stand)	248.7 mm
Width (with stand)	806.8 mm
Height (with stand)	605.6 mm
Weight (with stand)	13100 g
Depth (without stand)	79 mm
Width (without stand)	806.5 mm
Height (without stand)	552.6 mm
Weight (without stand)	10700 g
