EXPLODED VIEW PARTS LIST
No. PART NO. DESCRIPTION
120 EAB33496901 Speaker,Full Range 5B084 ND 10W 8OHM 82DB 120HZ 147 X 42 X 31 LUG
200 EAJ37543301 LCD,Module-TFT LC320WX4-SLD2 WXGA 8ms(GTG),Zero RT Pol. 10000K LG PHILIPS LCD
210 MJH32520201 Supporter PRESS EGI 1.2t GUIDE EGI METAL BAR, TOP (32LC4)
MJH32520205 Supporter PRESS EGI 1.2t GUIDE EGI METAL BAR, TOP 32LC4R-ZA C/SKD
220 MJH32520401 Supporter PRESS EGI 1.2t GUIDE EGI METAL BAR, BOTTOM (32LC4)
MJH32520405 Supporter PRESS EGI 1.2t GUIDE EGI METAL BAR, BOTTOM 32LC4R-ZA C/SKD
230 MJH32520501 Supporter PRESS EGI 1.0t GUIDE EGI METAL BAR, FOR POWER (32LC4)
MJH32520503 Supporter PRESS EGI 1.0t GUIDE EGI METAL BAR, FOR POWER ,32LC4R-ZA C/SKD
240 MJH32520602 Supporter PRESS EGI 1.0t GUIDE EGI METAL BAR, MIDDLE, V668, D2A
MJH32520605 Supporter PRESS EGI 1.0t GUIDE EGI METAL BAR, MIDDLE, 32LC4 C/SKD
250 MJH32520702 Supporter PRESS EGI 1.0t GUIDE EGI METAL BAR, FOR MAIN , D2A
MJH32520703 Supporter PRESS EGI 1.0t GUIDE EGI .METAL BAR, 32LC4 C/SKD
260 MGJ32973601 Plate PRESS SECC 1.6 SUPPORTER SBHG-A METAL JIG BOTTOM
300 ABJ32467302 Cabinet Assembly 32LC7DA LT73A 32” CABINET ASSY FOR TAIWAN
ABJ32885603 Cabinet Assembly 32LC52-ZC LP78A 32” H&C + DIRECT Hole, C/SKD
ABJ32885604 Cabinet Assembly 32LC7R-ZA LP78A 32” H&C C/A + DIRECT HOLE
301 ABA33223901 Bracket Assembly GRILLE 32LC7 LP78A
400 ACQ32467601 Cover Assembly,Rear 32LC7R-ZA LP78A 32” BACK COVER ASSEMBLY
ACQ32467606 Cover Assembly,Rear 32LC7R-ZA LP78A 32” BACK COVER ASSEMBLY FOR C/SKD
ACQ32467612 Cover Assembly,Rear 32LC7R-ZA LP78A 32” BACK COVER ASSEMBLY PHANTOM FOR EU
ACQ32467620 Cover Assembly,Rear 32LC51/7R-ZA LP78A - PHANTOM 32” BACK COVER ASSEMBLY
430 AAN31752702 Base Assembly STAND 32LC4D-NF LA64F STAND ASSY HEAT&COOL
AAN31752703 Base Assembly STAND 32LC4 TOOL LA64F STAND ASSY C/SKD
AAN31752704 Base Assembly STAND 32LC4 TOOL LA64F STAND ASSY C/SKD H&
520 EBR35512904 Hand Insert PCB Assembly MAIN M.I LP78A H4 EU MAIN . HAND INSERT For LGEWR
EBR35512905 Hand Insert PCB Assembly MAIN M.I LP78A H4 EU MAIN FOR CKD From China To WR
EBR35843501 PCB Assembly MAIN T.T LP78A 32LC4R-ZA . Total
EBR35843504 PCB Assembly MAIN T.T LP78A 32LC4R-ZA . Main Total For CKD . China
530 EBR36204701 PCB Assembly,Sub SUB T.T LP78A H4 26LCD Model . CONTROL
EBR36204702 PCB Assembly,Sub SUB T.T LP78A H4 LCD Model CONTROL . FOR CKD
580 EAY34795001 Power Supply Assembly LGIT_32inch FREE Tornado 32inch LCD LGIT LCD Tornado 32inch
590 EBR35685301 PCB Assembly,Sub SUB T.T LP78A 32LC7R . PRE-AMP IR
EBR35685302 PCB Assembly,Sub SUB T.T LP78A 32LC7R . PRE-AMP IR For CKD
591 MES36332301 Indicator MOLD ABS LED&PRE AMP 47LC7 PMMA 7 PHY NONE
MKC34384901 Window MOLD PMMA WINDOW 32/37/42/47LC7 PMMA LED & PRE AMP
600 EBR35705201 PCB Assembly SUB T.T LP78A 32LC7R . SIDE
EBR35705202 PCB Assembly SUB T.T LP78A 32LC7R . EU SIDE For CKD
