- 25 -
EXPLODED VIEW PARTS LIST
No.
PART NO.
DESCRIPTION
120 EAB33496901 Speaker,Full Range 5B084 ND 10W 8OHM 82DB 120HZ 147 X 42 X 31 LUG ESTEC
200 EAJ37543301 LCD,Module-TFT LC320WX4-SLD2 WXGA 32INCH 1366X768 500CD COLOR 72% 16/9
201 MJH32520204 Supporter PRESS EGI 1.2t GUIDE EGI METAL BAR, TOP (32LC5) Europass3
202 MJH32520404 Supporter PRESS EGI 1.2t GUIDE EGI METAL BAR, BOTTOM (32LC5) Europass3
203 MJH32520501 Supporter PRESS EGI 1.0t GUIDE EGI METAL BAR, FOR POWER (32LC4)
204 MJH32520601 Supporter PRESS EGI 1.0t GUIDE EGI METAL BAR, MIDDLE (32LC4)
205 MJH32520701 Supporter PRESS EGI 1.0t GUIDE EGI METAL BAR, FOR MAIN (32LC4)
206 MGJ32973601 Plate, PRESS SECC 1.6 SUPPORTER SBHG-A METAL JIG BOTTOM
300 ABJ32467302 Cabinet Assembly 32LC7DA LT73A 32” CABINET ASSY FOR TAIWAN
ABJ32885603 Cabinet Assembly 32LC52-ZC LP78A 32” H&C + DIRECT Hole, C/SKD
301 ABA33223901 Bracket Assembly GRILLE 32LC7 LP78A -
400 ACQ32467621 Cover Assembly,Rear 32LC55/7D-ZA LD73A - PHANTOM 32” EUROPASS3 BACK COVER
430 AAN31752703 Base Assembly STAND 32LC4 TOOL LA64F STAND ASSY C/SKD
AAN31752704 Base Assembly STAND 32LC4 TOOL LA64F STAND ASSY C/SKD H&C
520 EBR37029503 PCB Assembly,Main MAIN1 T.T LD73A 32LC4D-ZA SEUVLJG Separation-Tuner MAIN TOTAL
521 MJH32521103 Supporter PRESS EGI 0.5t GUIDE EGI METAL, REAR SHIELD (32LC4)
MJH32521113 Supporter PRESS EGI 0.5t GUIDE EGI METAL, REAR SHIELD (32LC4/7D-ZA)
530 EBR34778401 PCB Assembly,Sub SUB T.T LD73A 37LC4D-ZN AEULLHX CONTROL TOTAL
580 EAY34795001 Power Supply Assembly LGIT_32inch FREE Tornado 32inch LCD LGIT LCD Tornado 32inch
590 EBR35734601 PCB Assembly,Sub SUB T.T LD73A 42LC7D-ZA AEUVLHX IR/LED TOTAL
591 MKC34384901 Window MOLD PMMA WINDOW 32/37/42/47LC7 PMMA LED & PRE AMP
MES36332301 Indicator MOLD ABS LED&PRE AMP 47LC7 PMMA 7 PHY NONE
600 EBR36262801 PCB Assembly,Sub SUB T.T LD73A 32LC7D-ZA AEUVLHX SIDE A/V TOTAL
