P800 Pin #20
Voltage level = 2V
Check Power connector
OK ?
Replace Power Board
YES
NO YES
NO
YES
Replace MAIN B’D Q802
MAIN B’D L1300 = 12V ? Replace MAIN B’D Q806
NO
Replace Main Board
YES
P800 Pin #13, 14 = 12V
P800 Pin #17, 18 = 24V ?
Check LVDS Cable
OK ?
YES
Replace LVDS Cable
NO
Making
Revision
2009. 2 . 1
LCD TV
Symptom
No OSD
26~42LH2000
32~47LH3000/LH4000
3/34
