LG 47LN5700 User Manual

ENGLISH
22
MAKING CONNECTIONS
Composite Connection
Transmits analog video and audio signals from an external device to the TV. Connect the external device and the TV with
the composite cable as shown in the following illustration.

Check to ensure the cables are matched with the corresponding color connection.
NOTE
P
C
-A
U
DI
O
IN
CO
MP
O
NENT IN
/
AV IN
P
B
P
R
VIDE
O
/
Y
L
/M
O
N
O
AUDIO
O
R
PC-AUDIO IN
VIDEO / Y
L/MONO
AUDIO R
VIDEO
MONO
( )
AUDIOL R
VCR / DVD / Blu-Ray / HD Cable Box
(*Not Provided)
YELLOW
WHITE
RED
YELLOW
WHITE
RED

LG 47LN5700 Specifications

General

Display diagonal	46.9 \
Native refresh rate	60 Hz
LED backlighting type	-
Supported video modes	1080i, 1080p, 720p
Screen format adjustments	4:3, 16:9, Zoom
Motion interpolation technology	TruMotion 120 Hz
3D	No
Audio system	Virtual Surround, Clear Voice II
RMS rated power	20 W
Number of speakers	2
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	1
Smart modes	Cinema, Game, Standard, Vivid
Audio formats supported	AAC, AC3, MP3, PCM
Image formats supported	JPG, MPO
Video formats supported	DIVX, MPEG
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	50.3 W
Sustainability certificates	ENERGY STAR
Package depth	175 mm
Package width	1329.94 mm
Package height	750 mm
Package weight	18415.8 g

Weight and Dimensions

Depth (with stand)	262.89 mm
Width (with stand)	1078.99 mm
Height (with stand)	693.9 mm
Weight (with stand)	14515 g
Depth (without stand)	80.5 mm
Width (without stand)	1079 mm
Height (without stand)	629 mm
Weight (without stand)	13108 g
