EXTERNAL CONTROL DEVICE SETUP
Communication Parameters
• Baud rate : 9600 bps (UART)
• Data length : 8 bits
• Parity : None
• Stop bit : 1 bit
• Communication code : ASCII code
• Use a crossed (reverse) cable.
Command reference list
(Depending on model)
COMMAND1 COMMAND2
DATA
(Hexadecimal)
COMMAND1 COMMAND2
DATA
(Hexadecimal)
01. Power* k a 00 to 01 15. Balance k t 00 to 64
02. Aspect
Ratio
k c (p.7)
16. Color
(Colour)
Temperature
x u 00 to 64
03. Screen
Mute
k d (p.7)
17. ISM
Method (Only
Plasma TV)
j p (p.8)
04. Volume
Mute
k e 00 to 01 18. Equalizer j v (p.8)
05. Volume
Control
k f 00 to 64
19. Energy
Saving
j q 00 to 05
06. Contrast k g 00 to 64
20. Tune
Command
m a (p.9)
07.
Brightness
k h 00 to 64
21. Channel
(Programme)
Add/Del(Skip)
m b 00 to 01
08. Color/
Colour
k i 00 to 64 22. Key m c Key Codes
09. Tint k j 00 to 64
23. Control
Backlight,
Control Panel
Light
m g 00 to 64
10.
Sharpness
k k 00 to 32
24. Input
select (Main)
x b (p.11)
11. OSD
Select
k l 00 to 01
25. 3D (Only
3D models)
x t (p.11)
12. Remote
Control Lock
Mode
k m 00 to 01
26. Extended
3D (Only 3D
models)
x v (p.12)
13. Treble k r 00 to 64
27. Auto
Configure
j u (p.12)
14. Bass k s 00 to 64
* Note: During playing or recording media, all commands except Power (ka) and Key (mc) are not
executed and treated as NG.
With RS232C cable, TV can communicate "ka command" in power-on or power-off status. but with
USB-to-Serial converter cable, the command works only if TV is on.

LG 49LJ510M Specifications

General

Screen Type	led
Wall Mount	300mm x 300mm
Tuner	digital
Screen Size	48.5 inches, 49 inches
Screen Technology	standard led
Resolution	full hd (1080p)
Refresh Rate	60hz
Closed Captioning	yes
HDR	no
Built-In Speakers	yes
Speakers Output	10 watts
HDMI Ports	2
HDMI 2.1 Ports	0
HDMI ARC Ports	yes
USB Ports	1
Ethernet	no
RF Antenna	yes
Network	none
Digital Optical Audio Outputs	0
Component Video Inputs	1
Composite Video Inputs	1
DVI	0
Remote Control	standard
3D	no
Power Consumption	73 kilowatt hours
Depth with Stand	8.2 inches
Height with Stand	27.4 inches
Width with Stand	43.6 inches
Net Weight with Stand	24 pounds
Depth without Stand	3.2 inches
Height without Stand	25.9 inches
Net Weight without Stand	23.4 pounds
