- 25 -
101 5900904001A Fan Module 5900904001A 1.7KRPM DC 12V 250UA 3W 50HZ 1.5M3 per MIN 396X60.2X108.3MM DONGYANG..
120 EAB33775101 Speaker, Full Range EN1562C-6712 ND 10W 8OHM 82DB 100HZ 193.5 X 42 X 39.9 LUG KOREA TOPTONE
200 EAJ37050301 PDP, Module-XGA PDP50X40501.AKLGG XGA 50INCH 1365X768 16/9 PDP DIVISION LGERA
EAJ36484201 PDP, Module-XGA PDP50X40101.ASLGB XGA 50INCH 1365X768 16/9 PDP DIVISION
201 6871QCH083A Hand Insert PCB Assembly, 6871QCH083A , CTRL Board CTRL ASS’Y HAND INSERT 50” CTRL PDP DIVISION
202 6871QDH115A Hand Insert PCB Assembly, 6871QDH115A , Y DRIVE TOP YDRV ASS’Y HAND INSERT 50” X4 PDP DIVISION
203 6871QDH116A
Hand Insert PCB Assembly, 6871QDH116A , Y DRIVE BOTTOM YDRV ASS’Y HAND INSERT 50” X4 YDRV BTM PDP DIVISION
204 6871QLH063A Hand Insert PCB Assembly, 6871QLH063A , X_LEFT BOARD XRLT ASS’Y HAND INSERT 50” X4 PDP DIVISION
205 6871QRH073A Hand Insert PCB Assembly, 6871QRH073A , X_RIGHT BOARD XRRT ASS’Y HAND INSERT 50” X4 PDP DIVISION
206 6871QXH034A Hand Insert PCB Assembly, 6871QXH034A , X_CENTER BOARD XRCT ASS’Y HAND INSERT 50” X4 PDP DIVISION
207 6871QYH061A Hand Insert PCB Assembly, 6871QYH061A , Y_SUS BOARD YSUS ASS’Y HAND INSERT 50” X4 2 LAYER PDP DIVISION
208 6871QZH065A Hand Insert PCB Assembly, 6871QZH065A , Z_SUS BOARD ZSUS ASS’Y HAND INSERT 50” X4 2 LAYER PDP DIVISION
240 AJJ31591601 Supporter Assembly, 50PC5 SUPPORTER VERTICAL RIGHT LGERA
AJJ31591603 Supporter Assembly, 50PC5 SUPPORTER VERTICAL RIGHT FOR SKD
250 AJJ31591602 Supporter Assembly, 50PC5 SUPPORTER VERTICAL LEFT LGERA
AJJ31591604 Supporter Assembly, 50PC5 SUPPORTER VERTICAL LEFT FOR SKD
300 ABJ31591215 Cabinet Assembly, 50PC5D-ZB NON 50” 50PC5D-DB WITH STREAMER LGERA
ABJ31591204 Cabinet Assembly, 50PC5R-ZB NON 50” H&C 1PIECE FOR SKD
301 AJJ31592501 Supporter Assembly, 50PC5 SUPPORTER TOP ASSY LGERA
AJJ31592505 Supporter Assembly, 50PC5 SUPPORTER TOP ASSY FOR PHANTOM,LGEMA ASSY
302 AJJ31592601 Supporter Assembly, 50PC5 SUPPORTER BOTTOM ASSY LGERA
AJJ31592605 Supporter Assembly, 50PC5 SUPPORTER BOTTOM ASSY FOR PHANTOM,LGEMA ASSY
303 AJJ31592701 Supporter Assembly, 50PC5 SUPPORTER RIGHT ASSY LGERA
AJJ31592705 Supporter Assembly, 50PC5 SUPPORTER RIGHT ASSY FOR PHANTOM,LGEMA ASSY
304 AJJ31592801 Supporter Assembly, 50PC5 SUPPORTER LEFT ASSY LGERA
AJJ31592805 Supporter Assembly, 50PC5 SUPPORTER LEFT ASSY FOR PHANTOM,LGEMA ASSY
306 ABA31592901 Bracket Assembly, DECO 50PC5 NON DECO BRACKET ASSY (Direct Grill)
ABA31592901 Bracket Assembly, DECO 50PC5 NON DECO BRACKET ASSY (Direct Grill)
400 ACQ31591305 Cover Assembly, 50PC5R-ZB NON 50” PCM SECD 0.5t FOR LGEMA local
501 AGU31681101 Plate Assembly, ASSY PLATE TUNER BOT SMALL, 42PC5 LGERA
AGU31681115 Plate Assembly, ASSY PLATE TUNER BOT SMALL, 42PC5R-ZB, MA LCOAL
502 AGU31680901 Plate Assembly, ASSY PLATE TUNER COVER SMALL, 42PC5 LGERA
AGU31680921 Plate Assembly, ASSY 42PC5R-ZB(MA LOCAL)
520 EBR32773007 Hand Insert PCB Assembly, Main MAIN1 M.I PP78A H4 VCT-PRO 50PC5R-ZB. PDP 50” HAND INSERT LGERA
EBR32773024 Hand Insert PCB Assembly, Main MAIN1 M.I PP78A H4 VCT-PRO. 50PC5R SKD HAND INSERT SKD
EBR32773017 Hand Insert PCB Assembly, Main MAIN1 M.I PP78A H4 VCT-PRO 50PC5R-ZB. PDP 50” HAND INSERT FOR LGEMP CKD
560 EBR33804101 Hand Insert PCB Assembly, CONTROL M.I PP78A 50PC5R-ZA . H4 50INCH HAND INSERT LGERA
EBR33804108 Hand Insert PCB Assembly, CONTROL M.I PP78A 50PC5R-ZB . H4 50INCH SKD HAND INSERT
570 EBR33809701 Hand Insert PCB Assembly, SUB M.I PP78A 50PC5R-ZA . H4 PREAMP HAND INSERT LGERA
EBR33809706 Hand Insert PCB Assembly, SUB M.I PP78A 50PC5R-ZB . H4 PREAMP SKD HAND INSERT
580 EAY32929001 SMPS, AC/DC 1H372W 100VTO240V 530W 50 TO 60HZ UL/CE/TUY 50INCH PDP XPOWER SANKEN PSU 1H372W ..
590 EAM35012703 Filter, AC LineIF2-N06CEWL2 5.3mH 250VAC 6A 0.22uF 1000pF VDE/CSA/K/CCC 450/130MM CORE ADDTION..
600 EBR33799302 Hand Insert PCB Assembly, SUB M.I PP78A 50PC5R-ZA . SIDE AV HAND INSERT LGERA
EBR33799328 Hand Insert PCB Assembly, SUB M.I PP78A 50PC5R-ZB . SIDE AV HAND INSERT
601 MJH32554901 Supporter, PRESS SBHG 1 GUIDE EGI 42PC5, SUPP. SIDE AV
602 MGJ32369301 Plate,Shield PRESS SPTE 0.3 SHIELD SPTE 42PC5, SHIELD CASE SIDE AV
603 ABA31583301 Bracket Assembly, SIDE AV 42PC5 AB
900 AAN31593101 Base Assembly, STAND 50PC5 NON 50PC5 FIX STAND LGERA
AAN31593104 Base Assembly, STAND 50PC5 NON 50PC5 FIX STAND FOR “PLASMA DISPLAY PANEL” SKD
901 MCK32604801 Cover, MOLD ABS 42PC5 ABS CABLE MANAGEMENT
EXPLODED VIEW PARTS LIST
No. Part No. Descriptions
The components identified by mark is
critical for safety.
Replace only with part number specified.
