PRODUCT SPECIFICATIONS
The product specifications below may be changed without prior notice due to upgrade of product functions.
“ ” refers to alternating current (AC), and “ ” refers to direct current (DC).
OLED screen Screen type
Thin Film Transistor (TFT)
OLED Screen
Operating conditions Daily usage 18 hours (video)
Video signal
Maximum resolution
HDMI/DISPLAYPORT: 3840x2160 @ 30Hz
- This may not be supported on some OS or graphics card
types.
Recommended
resolution
HDMI/DISPLAYPORT: 1920x1080 @ 60Hz
- This may not be supported on some OS or graphics card
types.
Horizontal frequency HDMI/DISPLAYPORT: 30kHz to 83kHz
Vertical frequency HDMI/DISPLAYPORT: 56Hz to 60Hz
Synchronization Separate Sync, Digital
Input/Output ports
USB 2.0 IN 2, HDMI
TM
IN, DP IN, DP OUT, USB 2.0 IN 1, LAN IN, LAN OUT, IR IN,
RS-232C IN, RS-23C OUT, AUDIO OUT, LC OUT, LC IN
Embedded battery Applied
Environmental
Conditions
Operating Temperature 0°C to 40°C (32°F to 104°F)
Operating Humidity 10% to 80%
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Storage Humidity 5% to 85%
OLED Panel Pixel Pitch 0.630mm(H) x 0.630mm(V)
Power Rated Voltage 100-240V~ 50/60Hz 3.7A
Dimensions
(Width x Depth x
Height)
Display Module (Back
metal plate assembled)
55EF5K-L
1224.9 x 38 x 696.2(mm)
48.2 x 1.4 x 27.4(inches)
55EF5K-P
701.4 x 38 x 1219.7(mm)
27.6 x 1.4 x 48(inches)
Signage Box
413 x 57.3 x 353(mm)
16.2 x 2.2 x 13.8(inches)
Weight
55EF5K-L
9.3(kg)
20.5(lbs)
55EF5K-P
10.5(kg)
23.1(lbs)
