SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
1. Application range
This spec sheet is applied LCD TV with (LA23G) chassis
2. Test condition
Each part is tested as below without special notice.
1)
Temperature : 25
ºC
± 5
ºC
(77±9
ºF
), CST : 40±5
ºC
2) Relative Humidity: 65 % ± 10 %
3) Power Voltage
- AC 100-240 V~, 50/60 Hz
* Standard Voltage of each products is marked by models.
4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
5) The receiver must be operated for about 5 minutes prior to
the adjustment.
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety : UL, CSA, CE, IEC specification
- EMC: FCC, ICES, CE, IEC specification
- Wireless : WirelessHD Specification (Option)
4. General Specification
No Item Specication Remark
1 Market 1) North America
2 Broadcasting System 1) ATSC / NTSC
3 Receiving System 1) VSB/64 & 256 QAM/ NTSC-M
4 Input Voltage AC 100 ~ 240V 50/60Hz FHD + T120Hz
5 Available Channel 1) VHF : 02~13
2) UHF : 14~69
3) DTV : 02-69
4) CATV : 01~135
5) CADTV : 01~135
6 Screen Size 47/55 inche Wide(1920 × 1080)
7 Aspect Ratio 16:9
8 Tuning System FS
9 LCD Module LC470EUE-SEF1 Edge LED Module T120Hz V12
LC550EUE-SEF1 Edge LED Module T120Hz V12
10 Operating Environment 1) Temp : 0 ~ 40 deg
2) Humidity : ~ 80 %
11 Storage Environment 1) Temp : -20 ~ 60 deg
2) Humidity : ~ 85 %
