SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
1. Application range
This spec sheet is applied to the LED TV used LA66L chassis
2. Test condition
Each part is tested as below without special notice.
(1) Temperature : 25 ºC±5 ºC (77 ºC±9ºC), CST : 40 ºC±5 ºC
(2) Relative Humidity: 65 % ± 10 %
(3) Power Voltage
Standard input voltage (100~240V@ 50/60Hz)
(4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
(5) The receiver must be operated for about 20 minutes prior
to the adjustment.
3. Test method
(1) Performance: LGE TV test method followed
(2) Demanded other specification
- Safety : UL, CSA, IEC specification
- EMC: FCC, ICES, IEC specification
4. General Specification
No Item Specication Result Remark
1. Receiving System ATSC / NTSC-M / 64 & 256 QAM
2. Available Channel VHF : 02~13
UHF : 14~69
DTV : 02-69
CATV : 01~135
CADTV : 01~135
3. Input Voltage AC 100 ~ 240V 50/60Hz Mark : AC 110~240V, 50/60Hz
4. Market NORTH AMERICA
5. Screen Size 32", 43”, 49", 55”
6. Aspect Ratio 16:9
7. Tuning System FS
8. Module LC550DUE-FJA1 LGD FHD
NC550DUE-VCCP3 CSOT FHD
NC490DUE-SADP3 LGD FHD
NC490DUE-ABEX1 BOE FHD
HC430DUN-SLVX1 LGD FHD
HC430DUN-ABVX1 BOE FHD
HC320DXN-ABVS1 BOE HD
HC320DXN-SLVS5 LGD HD
HC320DXN-VHVS1 SHARP HD
9. Operating Environment Temp : 0 ~ 40 deg
Humidity : ~ 80 %
10. Storage Environment Temp : -20 ~ 60 deg
Humidity : ~ 85 %
