LG CM8350 - Appendix; General Specifications

5 Appendix
Appendix38
Appendix
5
General specifications
General
Power requirements Refer to the main label.
Power consumption
Refer to the main label.
Networked standby : 0,4 W
(If all network ports are activated.)
Dimensions (W x H x D) 450 mm x 160 mm x 355 mm
Net Weight (Approx.) 5,8 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 60 %
Bus Power Supply 5 V
0
500 mA
Inputs
AUX IN 2,0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R)
PORT. IN 1,2 Vrms (3,5 Ø jack)
MIC 27 mV
Tuner
FM Tuning Range 87,5 to 108,0 MHz or 87,50 to 108,00 MHz
AM Tuning Range 522 to 1 620 kHz, 520 to 1 710 kHz or 522 to 1 710 kHz
CD
Frequency Response 40 to 20 000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 80 dB
Amplier
Total output RMS 2 000 W
FRONT RMS 500 W x 2 (6 Ω at 1 kHz)
REAR RMS 500 W x 2 (6 Ω at 5 kHz)
THD 25 %
y
Design and specications are subject to change without notice.
