General specifications
General
Power requirements Refer to the main label on the unit.
Power consumption
Refer to the main label on the unit.
Networked standby : 0,5 W
(If all network ports are activated.)
Dimensions (W x H x D) Approx. 450 mm x 160 mm x 355 mm
Net Weight Approx. 6 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 60 %
Inputs
Analog audio in (AUX IN) 2,0 Vrms (1 kHz, 0 dB), 600
Ω
, RCA jack (L, R)
Portable in (PORT. IN) 1.2 Vrms (3.5 mm stereo jack) x 1
Microphone (MIC 1/2) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 2
Tuner
FM Tuning Range 87,5 to 108.0 MHz or 87,50 to 108,00 MHz
System
Frequency Response 40 to 20,000 Hz
Signal-to-noise ratio More than 75 dB
Dynamic range More than 80 dB
Bus Power Supply (USB) 5 V
0
500 mA
Amplier (RMS Output power)
Total output 2,200 W
HIGH 550 W X 2 (6
Ω
at 5 khz, 25 % THD)
MID 550 W X 2 (6
Ω
at 1 khz, 25 % THD)
y
Design and specications are subject to change without notice.
