16
INSTALLATION
4. Remove the two latch screws and the latch.
5. Hold the hinge in place while removing the four hinge
screws (to prevent the door from dropping).
6. Remove the door from the cabinet cover.
1. Open the dryer door.
2. You will be removing the screws shown below
(6 on left, 4 on right).
3. Remove the four decorative screws on the left using a
screwdriver.
Reversing the door
Decorative
Hinge
Screw
Open Door
Remove
Door
Hinge Screw
Latch Screw
w
WARNING
THE DRYER DOOR IS VERY LARGE AND HEAVY. Failure
to follow the instructions below can result in damage
to the dryer, property damage or injury to persons.
the door.
CAUTION
Be sure to support the weight of the door before
removing the hinge screws.
MFL67731085_en_160809.indd 16 2016.8.9 5:41:20 PM
