ENGLISH
Description Steam Dryer
Electrical Requirements* Please refer to the rating label regarding detailed information.
Gas Requirements* NG 4-10.5 inches WC
LP: 8–13 inches WC (Gas Models only)
Dimensions 27" (W) X 30" (D) X 38
11/16" (H), 51" (D with door open)
68.6 cm (W) X 76.1 cm (D) X 98.3 cm (H), 129.7 cm (D with door open)
Net Weight 126 lbs(57.2kg)
Drying Capacity
- Normal Cycle
- Steam Cycle
*Refer to the rating plate on your dryer.
The appearance and specifications listed in this guide may vary due to constant product improvements.
KEY DIMENSIONS AND SPECIFICATIONS
STACKING KIT INSTALLATION (cont.)
3
Place the dryer on top of the washer by
fitting the dryer feet into the side brackets as
illustrated. Avoid finger injuries; do not allow
fingers to be pinched between the washer
and dryer. Slowly slide the dryer toward the
back of the washer until the side bracket
stoppers catch the dryer feet.
4
Insert the front rail between the bottom of
the dryer and the top of the washer. Push the
front rail toward the back of the washer until it
comes in contact with the side rail stoppers.
Install the two remaining screws to secure the
front rail to the side rails.
Washer
Dryer
IEC 7.3 cu.ft. (22.5 lb/10.2 kg)
IEC 7.3 cu.ft. (8 lb/3.6 kg)
Steam Dryer™ Models
DLEX 2550* DLGX2551* DLEX2450* DLGX2451* DLEX2650* DLGX2651*
47
