10
INSTALLATION
EN
Parts
1
Transit bolts
2
Power plug
3
Drawer
4
Control panel
5
Drum
6
Door
7
Drain hose
8
Drain plug
9
Drain pump lter
10
Cover cap (Location may
vary depending on products)
11
Adjustable feet
Accessories
Cold supply hose (1 EA)
(Option: Hot (1 EA))
Spanner Caps for covering
transit bolt holes
(Optional)
Anti–slip sheets (2 EA)
(Optional)
Elbow bracket for
securing drain hose
(Optional)
Tie strap (Optional)
