LG Flatron E2260S User Manual


Copyright © 2010 LG Electronics. Inc. All right reserved. - 25 - LGE Internal Use Only
Only for training and service purposes
EXPLODED VIEW PARTS LIST
Ref. No. TPV part No. LGE part No. Description
010
705GFACS009 ABJ73308502 BEZEL L215W-TLG4 WITH KEY BUTTON
020
KEPCAQG1
EBU60704503 KEY BOARD
030
LEPCAQG1
EBU60934810
LED BOARD
040
750GMT215W4A11M0LG COV30101221
PANEL LM215WF4 TRA1 FQ LTD
050
756GQACB KL002 00
EBU60714334 MAIN BOARD(CBPCAAWLGQ2)-E2260S
756GQACB KL003 00
EBU60714335 MAIN BOARD(CBPCAARLGQ2)-E2260T
060
Q15G0909101101 MDQ62638101
MAINFRAME-E2260S
Q15G0909101201 MDQ62638102
MAINFRAME-E2260T
070
705GFACS005
ACQ83873703 REAR COVER ASS'Y-E2260S
705GFACS007
ACQ83873704 REAR COVER ASS'Y-E2260T
080
705GFACS004
ACQ83873802 BASE ASS'Y
090
095G176J 10V01 COV30101415 FFC CABLE 10PIN 300MM 0.5MM
100
095G176J 50527 COV30101412 FFC CABLE 50 135 0.5
110
S95G80227506 NA HARNESS 7P-6P+3P 250/300
120
089G 725CAA 2G NA D-SUB CABLE 1500MM
