18
EN
Removing the Freezer Door
1
Remove the two hinge bolts.
2
Twist the hinge to raise the pivoting end so
that the door can be lifted off.
Lift the door off the lower hinge pin and
remove it.
3
Remove the door by lifting it off the lower
hinge pin.
Lower Hinge
Refitting the Freezer Doors
Mount the doors in the reverse sequence of
their removal once the appliance has been
passed through all access doors.
Adjusting the Height of the
Door
If the door is too low, lift the door up and screw
on a door hinge bolt in the manner shown
below using a spanner and a pair of long nose
pliers.
Adjusting the Fridge Door
Left Door
Open the fridge door and use the spanner type
1 to rotate the door hinge bolt as shown below.
Height difference
Fridge door
Freezer door
