Figure 9
2
Figure 7
LOWER HINGE
BOLT
Figure 8
3-4 FAN AND FAN MOTOR
1. Remove the freezer shelf.
2. Separate the Guide Ice Tray by pulling right.
3. Loose 1 screw.
4. Pull out the Grille Fan and Shroud-F.
SCREW
Figure 11
INSU' MULTI DUCT
THERMOSTAT
CONT' BOX-R
KNOB THERMOSTAT
COVER LAMP-R
HOLDER THERMOSTAT
Figure 10
3-3 THERMOSTAT
1. Remove the Cover Lamp-R by the use of ‘_’ type driver
inserting in the low holes of the cover.
2. Loose 2 screw.
3. Pull the Control Box-R.
4. Disconnect the Housing of lead wire.
5. Separate the INSU’MultiDuct and Control Box-R.
6. Diassemble the Knob..
7. Separate the Thermostat and Control Box-R.
8. Separate the Thermostat and Holder thermostat.
9. Disconnect the lead wire.
3-2 DOOR SWITCH3-1 DOOR
Freezer Door
Separating the Hinge Upper.
Open the freezer door and remove the Hinge Upper (2)
By unscrewing 2 screws (1). In this case, be careful not
To drop the freezer door. (Figure 6)
Separating the Freezer Door.2.
Refrigerator Door
1. Loosen hexagonal bolts fixing the Lower Hinge to the
2. Pull out the door gasket to remove from the door foam
Ass'y.
- 7-
1.
Open the freezer door to 90 degrees and grasp it with
right hand and grasp the Hinge Upper (2) with left hand.
Slide the freezer door to the Front so as to remove the
O
Hinge Upper (2) from the ceiling of the refrigerator, and
separate the freezer door by lifting it up. (Figure 7)
body to remove the refrigerator door only.
1. To remove the door switch, pull out it with a ‘_’ type
driver as shown in (figure 9).
2. Disconnect the lead wire from switch.
3. DISASSEMBLY
1
1
2
Figure 6
