REFRESHMENT CENTER (OPTIONAL)
OPERATIONS
1. Tilting: Grasp the front pocket and slightly lift it up
Then pull it forward to tilt the transparent door bin.
2. Closing: Then place the door bin in its original
position until you hear a "click"
GREEN ION DOOR COOLING
(OPTIONAL)
The anion coating in the duct cover purifies the air
and helps stored foods remain fresh longer.
If water of foreign substances enter the cool air vent
while cleaning, efficiency will be lowered. In addition,
if gasket is damaged, efficiency may be lowered owing to
the escape of cool air.
Cool air vent
DEODORIZER (OPTIONAL)
●
Unpleasant odor of food in fresh food
compartment is deodorized with no harm to
you and the food.
How to use
• As Deodorizer is located in cooling air inlet for circulating air in fresh food compartment, there is
no need for any handling.
• Do not prick the cooling air inlet with a sharp tip because Deodorizer may be damaged.
• When storing food with a strong odor, wrap it or store it in a container with a lid because odor may be
passed on to other foods.
Re-Using of Deodorizer
• Used some length and the odor is strong,
Deodorizer can be revived and re-used.
• Separate Deodorizer in ceiling of refrigerator
compartment, using hair drier to remove
moisture or malodor and oxidize under sunlight
to decomposing malodor by ultraviolet.
DEFROSTING
●
Defrosting takes place automatically.
●
The defrosted water flows down to the evaporating tray which located in
the lower back side of the refrigerator and is evaporated automatically.
REF. TEMP. CONTROL
MIN MAX
FRESH ZONE (OPTIONAL)
●
When the door is opened, the warmer air doesn't influence
in the fresh zone. So you can keep food fresher in it.
Tilt
Click
19
