26
ENG
ENGLISH
MAKING CONNECTIONS
Composite Connection
Transmits analog video and audio signals from an
external device to the TV. Connect the external
device and the TV with the composite cable as
shown.
VCR/ DVD/ Blu-Ray / HD Cable Box
YELLOW
YELLOW
RED
RED
WHITE
WHITE
(*Not Provided)
Headphone Connection
(Only LA643*/LA61**)
Transmits the headphone signal from the TV to
an external device. Connect the external device
and the TV with the headphone as shown.
NOTE
AUDIO menu items are disabled when
connecting a headphone.
When changing AV MODE with a
headphone connected, the change is
applied to video but not to audio.
Optical Digital Audio Out is not available
when connecting a headphone.
Headphone impedance: 16 Ω
Max audio output of headphone: 9mW to 15
mW
Headphone jack size: 0.35 cm
H/P OUT
(*Not Provided)
To Next Page
