Appendix

Specifications

General (LAS551H / LASC55)

Power requirements 120 V ~ 60 Hz

Power consumption

27 W

Networked standby : 2.5 W

(If all network ports are activated.)

Dimensions (W x H x D) 890 mm X 51 mm X 85 mm (31.8 inch x 2.0 inch x 3.3 inch)

Net Weight (Approx.) 2.8 kg (6.2 lb)

Operating temperature 41 °F to 95 °F (5 °C to 35 °C)

Operating humidity 5 % to 90 %

Input/Output

OPT. IN 3 V (p-p), Optical jack x 1

PORT. IN 0.5 Vrms (3.5 mm stereo jack) x 1

HDMI IN 19 Pin (Type A, HDMI™ connector) x 1

HDMI OUT 19 Pin (Type A, HDMI™ connector) x 1

Available Digital Input Audio

Sampling Frequency

32 kHz, 44.1 kHz, 48 kHz, 96 kHz

USB

Version 2.0

Bus Power Supply 5 V

500 mA

Amplier

Total 320 W

Front Middle/ Tweeter 40 W x 2 (4 Ω at 1 kHz) / 20 W x 2 (8 Ω at 12 kHz)

Subwoofer 200 W (3 Ω at 80 Hz)

THD 10 %

Wireless subwoofer (S55A1-D)

Power requirements 120 V ~ 60 Hz

Power consumption 33 W

Type 1 Way 1 Speaker

Impedance 3 Ω

Rated Input Power 200 W

Max. Input Power 400 W

Dimensions (W x H x D) 171 mm x 390 mm x 261mm (6.7 inch x 15.3 inch x 10.3 inch)

Net Weight (Approx.) 5.6 kg (12.3 lb)

Other manuals for LG LAS455H

Questions and Answers:

Need help?

Do you have a question about the LG LAS455H and is the answer not in the manual?

General

Audio decoders	-
RMS rated power	320 W
Audio output channels	2.1 channels
Audio Return Channel (ARC)	Yes
Product color	Black
Recommended usage	TV
Subwoofer type	Active subwoofer
Subwoofer sensitivity	85 dB
Subwoofer connectivity	Wireless
Impedance	4 Ω
Tweeter diameter	20 mm
Soundbar speaker RMS power	110 W
Signal-to-Noise Ratio (SNR)	82 dB
HDMI in	1
Bluetooth version	4.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	33 W
