- 6 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
1. Application range
This spec sheet is applied LED TV with LA49Bchassis
2. Test condition
Each part is tested as below without special notice.
1) Temperature : 25 ºC ± 5 ºC(77 ± 9 ºF) , CST : 40 ºC±5 ºC
2) Relative Humidity: 65 % ± 10 %
3) Power Voltage
Market Input voltage Frequency Remark
USA 110~240V 50/60Hz Standard Voltage of each
product is marked by
models
4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM
5) The receiver must be operated for about 20 minutes prior to
the adjustment
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety : UL, CSA, IEC specification
- EMC: FCC, ICES, IEC specification
4. General Specification
No Item Specication Result Remark
1. Receiving System 1) ATSC / NTSC-M / 64 QAM / 256 QAM
2. Available Channel 1) VHF : 02~13
2) UHF : 14~69
3) DTV : 02-69
4) CATV : 01~135
5) CADTV : 01~135
3. Input Voltage AC 110V, 60HZ Mark : 110V, 60Hz (N.America)
4. Market NORTH AMERICA
5. Screen Size 32/42 inch Wide (1920 × 1080) FHD + 60Hz 32LB5600-UZ
39LB5600-UZ
42LB5500-UZ
42LB5600-UZ
49LB5500-UZ
55LB5500-UZ
32 inch Wide (1366 × 768) HD + 60Hz 32LB550B-UZ
32LB560B-UZ
6. Aspect Ratio 16:9
7. Tuning System FS
To Next Page
