36 OPERATION
Folding Down the Upper Tines
Fold tines down to fit larger dishes; pull tines back up
to fit smaller dishes.
Loading Dishes & Pots
Height Adjustable Upper Rack
The upper rack adjusts up and down. Raise the
upper rack to allow items up to 14” tall in the lower
rack. Lower the upper rack to allow dishes up to 12”
tall in the upper rack. The dishwasher ships with the
upper rack raised.
There are three available positions for adjusting the
height of the upper rack to create more space.
1
2
3
2
3
1
Lowering the Rack:
Hold the rack at the center of each side to support its
weight. Then, push the button on each side to release
the rack and lower it to the lower position.
Raising the Rack:
Lift the rack at the center of each side until the
rack locks into place in the upper position. It is not
necessary to lift the lock levers to raise the rack.
