21
INSTALLATION
ENGLISH
3
Lower the door into final position and
tighten the screws located on both sides.
4
Insert the the top pullout drawer into the
frame, and push the drawer back into place
until you hear a click.
5
Slightly tilt up the front of the middle
drawer, insert the drawer into the frame,
and push it back into place.
6
Insert the lower basket in the rail
assembly.
Assembling the Freezer Drawer
1
With both hands, pull out each rail
simultaneously until both rails are fully
extended.
2
Grasp the drawer on each side and hook the
drawer supports into the rail tabs located on
both sides.
CAUTION
Do not hold the handle when removing
or replacing the drawer. The handle
may come off and it could cause
personal injury.
To Next Page
