9-1
P.C.B. PARTS LIST
LOC.
PART NO. DESCRIPTION SPEC SVC ALTER
NO.
AR1 0RZ1503G610 RESISTOR,DRAWING 150KOHM 1/4W 5% 3216 BULK 8 PIN R
BZ1 6908W3YA01B BUZZER TFM-57 CW NINGBO EAST PIEZO 2048HZ 70DB R 6908W3YA01A
C01 0CK1040K949 CAPACITOR,FIXED CERAMIC(HIGH DIELECTRIC) 0.1UF D 50V 80%,-20% F(Y5V) TA52 R
C02 0CE2276K618 CAPACITOR,FIXED ELECTROLYTIC 220UF SMS,SG 50V 20% FL TP 5 R
C03 0CE4771J618 CAPACITOR,FIXED ELECTROLYTIC 470UF SM,SA 35V 20% FL TP 5 R
C04 0CE1076D638 CAPACITOR,FIXED ELECTROLYTIC 100UF SMS,SG 10V 20% FM5 TP 5 R
C05 0CK1040K949 CAPACITOR,FIXED CERAMIC(HIGH DIELECTRIC) 0.1UF D 50V 80%,-20% F(Y5V) TA52 R
C06 0CH1223K566 CAPACITOR,FIXED CERAMIC(TEMP.COMPENSATE) 0.022UF 2012 50V 10% X7R R/TP R
C10 0CH1223K566 CAPACITOR,FIXED CERAMIC(TEMP.COMPENSATE) 0.022UF 2012 50V 10% X7R R/TP R
C11 0CE1076K638 CAPACITOR,FIXED ELECTROLYTIC 100UF SMS,SG 50V 20% FM5 TP 5 R
C20 0CK2230K949 CAPACITOR,FIXED CERAMIC(HIGH DIELECTRIC) 22NF D 50V 80%,-20% F(Y5V) TA52 R
C21 0CH1223K566 CAPACITOR,FIXED CERAMIC(TEMP.COMPENSATE) 0.022UF 2012 50V 10% X7R R/TP R
C25 0CH1223K566 CAPACITOR,FIXED CERAMIC(TEMP.COMPENSATE) 0.022UF 2012 50V 10% X7R R/TP R
C55 0CH1104K946 CAPACITOR,FIXED CERAMIC(TEMP.COMPENSATE) 0.1UF 2012 50V 80%,-20% Y5V(F) R/TP R
C80 0CH1221K566 CAPACITOR,FIXED CERAMIC(TEMP.COMPENSATE) 220PF 2012 50V 10% X7R R/TP R
C81 0CH1221K566 CAPACITOR,FIXED CERAMIC(TEMP.COMPENSATE) 220PF 2012 50V 10% X7R R/TP R
C82 0CH1221K566 CAPACITOR,FIXED CERAMIC(TEMP.COMPENSATE) 220PF 2012 50V 10% X7R R/TP R
C83 0CH1221K566 CAPACITOR,FIXED CERAMIC(TEMP.COMPENSATE) 220PF 2012 50V 10% X7R R/TP R
C84 0CH1221K566 CAPACITOR,FIXED CERAMIC(TEMP.COMPENSATE) 220PF 2012 50V 10% X7R R/TP R
CR1 6212W5YA03A RESONATOR,CRYSTAL GST8.0 MURATA 8MHZ +/-0.5% 15PF TP NONE R
CU1 4850W4C001A CUSHION 3.5T 15W 40L RUBBER BLACK R
D01 0DD400209AD DIODE 1N4002 PYUNG CHANG TP52 DO41 100V 1A 30A R
D02 0DD400209AD DIODE 1N4002 PYUNG CHANG TP52 DO41 100V 1A 30A R
D03 0DD400209AD DIODE 1N4002 PYUNG CHANG TP52 DO41 100V 1A 30A R
D04 0RD1002F609 RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA52 R
D10 0DD400209AD DIODE 1N4002 PYUNG CHANG TP52 DO41 100V 1A 30A R
D20 0DD414809AD DIODE 1N4148 PYUNG CHANG TP52 DO35 100V 0.5A 0 R
D30 0DD414809AE DIODE 1N4148M PYUNG CHANG TP52 DO34 60V 0.5A 0 R
D31 0DD414809AD DIODE 1N4148 PYUNG CHANG TP52 DO35 100V 0.5A 0 R
D32 0DD414809AE DIODE 1N4148M PYUNG CHANG TP52 DO34 60V 0.5A 0 R
D33 0DD414809AE DIODE 1N4148M PYUNG CHANG TP52 DO34 60V 0.5A 0 R
D34 0DD414809AE DIODE 1N4148M PYUNG CHANG TP52 DO34 60V 0.5A 0 R
D60 0RD1002F609 RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA52 R
D90 0DD414809AD DIODE 1N4148 PYUNG CHANG TP52 DO35 100V 0.5A 0 R
D91 0DD414809AD DIODE 1N4148 PYUNG CHANG TP52 DO35 100V 0.5A 0 R
D92 0DD414809AD DIODE 1N4148 PYUNG CHANG TP52 DO35 100V 0.5A 0 R
D93 0DD414809AD DIODE 1N4148 PYUNG CHANG TP52 DO35 100V 0.5A 0 R
D94 0DD414809AD DIODE 1N4148 PYUNG CHANG TP52 DO35 100V 0.5A 0 R
D95 0DD414809AD DIODE 1N4148 PYUNG CHANG TP52 DO35 100V 0.5A 0 R
D96 0DD414809AD DIODE 1N4148 PYUNG CHANG TP52 DO35 100V 0.5A 0 R
DP1 6302W5A002D DIGITRON VFD25-0709 ZEC 7 MS-117YT 7 SCROLL R 6302W5A002A
PT1 6010W2P043P TRANSFORMER,POWER 120V 60HZ DC 12V / AC 3.4V LGETA LEADER( R 6010W2P043A
PTC1 6322W5A007A THERMISTOR,NTC MMT-0.1CD-SP2388 SINGI INDUSTRY 100KOHM R
Q01 0TR126609AA TRANSISTOR,BIPOLARS KTA1266-Y(KTA1015) KEC TP TO92 50V 150MA R
Q02 0TR150509AC TRANSISTOR,BIPOLARS KTA1505-Y-T1(AZY) KEC TP TO92 50V 100MA R
Q20 0TR387509AB TRANSISTOR,BIPOLARS KTC3875S-Y-T1(ALY) KEC TP TO92 50V 150M R
Q30 0TR320209BA TRANSISTOR,BIPOLARS KEC KTC3202-O TP TO92 50V 150MA R
Q31 0TR107009AC TRANSISTOR,BIPOLARS KRA107S-T1 KEC TP TO92 50V 100MA R
Q32 0TR105008CA TRANSISTOR,BIPOLARS KRC105S KEC R/TP SOT23 50V 100MA R
Q33 0TR107009AC TRANSISTOR,BIPOLARS KRA107S-T1 KEC TP TO92 50V 100MA R
R:SERVICE PARTS
