LG LW1200PR User Manual

Service Manual 41
Replacement Parts List
Replacement Parts List
130410 BASE PAN WELD ASS'Y 3041A20020J R
130910 CABINET ASS'Y 3091A10032C R
135312 FRONT GRILL ASS'Y 3531A20098A R
135313 INLET GRILLE 3530A20037A R
135500 COVER, CONTROL BOX 3550A30114A R
145200 LINK 4520A20007A R
147581 HORIZONTAL LOUVER 4758A20018A R
147582-1 VERTICAL LOUVER 4758A20041A R
147582-2 VERTICAL LOUVER 4758A20041B R
148000 BRACE 4800A30002B R
149980 SHROUD 4999A20001A R
152302 AIR FILTER ASS'Y 5231A20007A R
152312 PLASMA FILTER ASS'Y 5983A10009H - R
237200 CONTROL PANEL 3720A10061A R
249950 CONTROL BOX ASS'Y 4995A20194A 4995A20194G R
268712 DISPLAY PCB ASS'Y 6871A20168A 6871A20186A R
238310 ESCUTCHEON 3831A10020A 3831A10021A R
268714 MAIN PCB ASS'Y 6871A20167A 6871A20167C R
263230 THERMISTOR ASS'Y 6323A20004D R
264110 POWER CORD ASS'Y 6411A20011H R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20052A 6711A20034G R
346811 MOTOR ASS'Y 4681A20027W R
349001 VENTILATION DAMPER 4900A20002A R
349480 ORIFICE 4948A10015A R
552111 TUBE ASS'Y CAPILLARY 5211AR3332W R
352113 DISCHARGE TUBE 5211AR2930Q R
352115 TUBE FORMED, EVAPORATOR 5211A20388B R
35211A SUCTION TUBE ASS'Y 5211A20228E R
352390 AIR GUIDE ASSEMBLY 5239A2004A R
354210 EVAPORATOR ASS'Y 5421A20099A R
567502 OVERLOAD PROTECTOR 6750U-L029A R
550140 ISOLATOR, COMP 4830AR4335A R
554030 CONDENSER ASS'Y 5403A20042D R
554160 COMPRESSOR 2520UKGC2BA R
559011 FAN 5900AR1173A R
359012 TURBO FAN 5900A20019A R
W0CZZ CAPACITOR 0CZZA20001N R
W48602 CLAMP, SPRING 3H02932B R
DESCRIPTION
PART NO.
REMARK
LW1200PR LW1200ER
LOCATION
NO
.
