LG LZ-H2006BA0 User Manual

Descriptions for operation and functions
14 Ventilation System
Descriptions for operation and functions
Main Body
1
5
6
2
4
3
Models: LZ-H0106BA0 / LZ-H0156BA0
1. Blower for Air Supply
A blower for sucking outside air.
2. Control Box
3. Blower for Exhausting
A blower for draining polluted air outside.
4. Maintenance cover
5. Total Heat Exchanger
Exchanges temperature and moisture between air
supply air and exhaust air.
6. Air Filter
Prevents clogging of the Total heat exchanger due to
❈ The figure of Total heat Exchanger can be different by the Product Model.
❈ The figure of Total heat Exchanger can be different by the Product Model.
1
5
4
6
2
3
1. Air Filter
Prevents clogging of the Total heat exchanger due to
dust.
2. Total Heat Exchanger
Exchanges temperature and moisture between air
supply air and exhaust air.
3. Blower for Exhausting
A blower for draining polluted air outside.
4. Control Box
5. Blower for Air Supply
A blower for sucking outside air.
6. Maintenance cover
Models: LZ-H0256BA0
